Mercury IXA530i User Manual

Kobian ixa530i: quick start
Hide thumbs

Advertisement

Quick Links

Download this manual
The MP3 player is a brand-new generation of digital portable device, supporting
multiple music formats including MP1, MP2, MP3, WMA, WMV, ASF and WAV, etc. Its
perfect sound quality, great reliability and exquisite appearance make it a masterpiece.
Devoutly hope to bring you great enjoyment in this digital era.
Unique Features
● Exquisite Appearance
Unique appearance designed and comfortable for handling
● Multi-Codec Player
e.g.: MP1, MP2, MP3, WMA, WMV, ASF and WAV Music formats
● Firmware Upgrade
Providing the latest updated features via firmware upgrade from the website
● FM Function
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IXA530i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mercury IXA530i

Summary of Contents for Mercury IXA530i

  • Page 1 The MP3 player is a brand-new generation of digital portable device, supporting multiple music formats including MP1, MP2, MP3, WMA, WMV, ASF and WAV, etc. Its perfect sound quality, great reliability and exquisite appearance make it a masterpiece. Devoutly hope to bring you great enjoyment in this digital era. Unique Features ●...
  • Page 2 You may easily listen to FM stations and set your favorite stations by using Auto search or Manual Search. The player can save 40 (20 for each Band) local stations . ● Drive Free U Disk You may manage your files directly through “Portable Disk” in “My Computer” on Winows2000 Operating System or above without driver.
  • Page 3 You may set Sleep Timer or Off Time mode in your own convenience. ● GUI (Graphic User Interface) Menu Vivid animation menu with corresponding characters make it easy to operate. Declaration Thank you for your purchase. Please read this manual carefully before using your new player. Contents in this manual may change possibly for better service.
  • Page 4 1. Locating the Controls Appearance & Keys...
  • Page 5 LCD Window Battery The player is in 9-level battery monitoring system. indicates that battery is 3.6V and the power in battery will become less when using. indicates low battery power and new battery should be charged up. 2. Basic Operation .
  • Page 6 Pressing MODE button may enter the menu system, including main menu (long press MODE button at Stop state), submenu at Play state (press to enter) and submenu at stop state (press to enter). . Browsing ○Browsing music files or menu options : ○...
  • Page 7 Record mode: FM mode: USB mode: Remark : long press Mode button to return to the main menu .when connecting the USB cable to PC, then will enter USB mode. .Volume Control press/long press the Next/prev button to adjust volume directly .
  • Page 8 1.Turn ON/Off manual ♦ when the player is in state of turn off, long press Play button ，and then turn on ♦ when the player is in state of turn on ,long press Play button， and then turn off Play & Stop (Pause when recording) Artifice: You may press Play button to fast exit from any menu or option interfaces.(e.g.: Volume Control Interface) 3.
  • Page 9 Play Enter main menu Enter Stop submenu Next song Continuous forward browse Previous song Continuous backward browse increase volume increase volume continuously decrease volume decrease volume continuously Action FM Status long press Power off stop enter main menu Enter Play submenu play next song fast forward play previous song...
  • Page 10 when station exists: next station; Press when without station: X long press enter main menu Press enter main menu increase 100KHz gradually or stop Press search Long press Increase 100KHz search continuously decrease 100KHz gradually or stop Press search Long press decrease 100KHz search continuously Press increase volume...
  • Page 11 2. Choose music PREV button ：to choose previous music NEXT button : to choose next music 5. Volume control VOL+ button: increase volume VOL- button: decrease volume 6. EQUALIZER Mode 1.When playing music 2.Press the MODE button to enter Play Submenu 3.Press NEXT button to choose Equalizer menu option...
  • Page 12 4.Press the MODE button to enter EQ mode selection Menu. 5.Press NEXT button to switch, and press MODE button to confirm 5. Play Recorded Files 1.Enter the main menu : 2. Press NEXT button to choose “Voice mode” 3. Press Mode button to enter Voice mode interface.
  • Page 13 4. Press PLAY button to start playing. 5. Select recorded files: PREV : to select the previous recorded file NEXT: to select the next recorded file 6. Operate FM Tuner 1. Enter the main menu 2. Press NEXT switch to select FM Mode. 3.
  • Page 14 4. Press Mode button to enter FM submenu, 5．Auto Search At FM submenu select “ Auto Search” option and press Mode button to confirm , then the player can auto scanned frequency between 87.5MHZ and 108MHZ and save to scanned station 6.
  • Page 15 Press NEXT: forward 100KHz 7. Save the manual searched stations Enter FM submenu and search “Save” option, and then Again press MODE button to save current station. 8. Listen to the saved stations. If there exist more than one station, press PLAY button to listen to the station in sequence.
  • Page 16 Note: The player supports US Band (FM87 - 108MHz) and Japan Band (FM76-90MHz), suitable for different area. (Press MODE button to enter FM submenu, and press NEXT button to select desirable frequency channel. If the current station is in STEREO status, such icon “ the LCD.
  • Page 17 Parameters Introduction (Record tiom） Set the time and date when recorded file are saved Set a fixed time after which the player may turn off the （SCREEN） (Language) Set different language displayed (Power Off) Set a fixed time after which the player may turn power off automatically (Replay mode) Set working states on Replay mode...
  • Page 18 3. Press VOL+ to set time in sequence of “YY-MM-DD” (Press VOL- to set in opposite sequence) 4.press NEXT / PREV button to adjust numbers Number of Year increasing: 5. Press Mode button to confirm and exit the current interface. ○...
  • Page 19 automatically. If “0” is selected, function is invalid. Operating steps is as follows: 1．At System Setting interface, Push Next key to select “Screen Time” option 2．Press Mode button to enter “Screen Time” setting interface: 3．Push Next/Last button to adjust time 4．Press Mode to confirm and exit.

  • Page 20: Power Off

    2．Press Mode button to enter “Language” setting interfance: 3．Push NEXT/Prev button to select desired language. 4．Press Mode to confirm to exit. ○ Power Off Operating steps refer to Language setting. Off Time mode refers that after a fixed period of time (unit: second) when no operation on keys at Stop mode, the player may turns off automatically to save power.
  • Page 21 for the player to turn off automatically when no keys operation no matter which mode it is at. This function is specially designed for listening to music before sleep. Note: Setting of Sleep Timer is valid only once and the set time will be cleared after power off.

  • Page 22: Memory Info

    Operating steps refers to Equalizer setting. Some operating systems (under Windows 2K SP4) can not support two driver letters in one USB disk. Thus, if “Private Space” function is on, choose which disk you are going to use, i.e., “single ordinary disk” or “single encrypted disk”, in order for correct display of selected disk after connecting to PC.
  • Page 23 The player supports standard USB disk function with operating system of Windows98 (driver needed), Windows 2K and above (driver free), Mac OS 10.3 and above, Linux 2.4.2 and above. The player supports power supply through USB. At waiting Mode, press MODE to exit to main menu, then select to enter desired mode.

  • Page 24: Created New Folder

    ○Created new folder The player can identify the 99 folders set up in the 7、Firmware Upgrade The player supports firmware upgrading or maintenance through installing special tools on PC. Enter the main menu. Press NEXT button to select “System Setting” U-disk.
  • Page 25 Press MODE button to enter System Setting. .Press NEXT button to choose “Firmware upgrade” option Press MODE button to enter “firmware upgrade” interface: Connect the player to PC Run the “MP3 Player Update” program in upgrading tools on PC, then click “choose firmware of new...
  • Page 26 version” button. the UI is as follows: Choose new firmware program (You may find it in accessory CD or download form our websit e.）...
  • Page 27 Click “Start” button, the system starts upgrading. If upgrading successfully, OLED will display as follows:...
  • Page 28 Notice: Firmware upgrade is an operation to promote and optimize the performance of the player. Even if the firmware works without upgrading, there is no any influence on the normal operation of the player. Incorrect operation of firmware upgrading may cause the player working abnormally. Please read the manual carefully before operation and firmware upgrading should be operated by the people with basic knowledge in computer operation.
  • Page 29 advance), to manage and play files according to different types. The player supports identification of 99 subdirectories. 1. At Stop interface . (Current example is at Music Mode, and folders can be selected at both Record and Voice Mode.) Press MODE button to enter Stop Submenu. Press MODE button again to enter Select Folder interface.
  • Page 30 6. Press MODE button to confirm the folders selected. Note: Independent folders can be set at corresponding modes as Music Mode, Record Mode and Voice Mode, i.e., three modes are not bound to correspond with the same folder. Delete File (At Stop Submenu) Files and FM stations can be deleted at corresponding modes as Music Mode, Voice Mode and FM Mode.
  • Page 31 3. Press NEXT/PREV buttons to choose “Delete” or “Delete All”. 4. Press MODE button to enter Delete Interface. 5. Press NEXT button to switch between “NO” and “YES”. 6. Press MODE button to confirm and deletion starts.
  • Page 32 Remark: “Delete All” means to delete all the relevant files at current mode in current folder. (For example, at Music Mode executing “Delete All”, all the music files in current files may be deleted, while recorded files without change.) The deleting interface is much simpler at FM Mode, only to the 3 saved stations to be deleted.
  • Page 33 The first option in Play Submenu is Play Mode. The player will play files according to the mode selected. Tempo Rate (Play Submenu) When playing music(Only for MP3 formats) or recorded files, different tempo rate can be set (faster or slower) without changing the tone and sound. files 1.
  • Page 34 2. Press MODE button to enter Play Submenu is as follows: 3. Press NEXT button to choose Tempo Rate option 4. Press MODE button to enter Tempo Rate interface is as follows: 5.Press NEXT button to quicken tempo rate and Press PREV button to slow down tempo rate.
  • Page 35 Private Space function Many MP3 users are puzzled by the problem of information disclosure and private data accessed by others. When others borrow MP3, you may have to delete the private information, which may cause big bother. However, the “Private Space” function provided by this player completely solves the bothering problem.
  • Page 36 Connect the player to PC. Run the accessory installation tools “MP3 Player Disk Tool”. The first is format tool. Choose “Partition and encrypt” option, and set a desired capacity for the encrypted disk, then choose the setting of username or password. Fill the username in the blank “New username”, and password in the blank “New password”, then input the same password again in the blank “New password...
  • Page 37 Confirm”. After the above operation, click “Start” button, and partition starts.
  • Page 38 Partition finishes with hints as follows: Press “OK”, then PC may restart. Two disks may be displayed after restarting (only one driver letter may be displayed when under Windows 2K SP4). Click to access the encrypted disk and there is a executable file...
  • Page 39 Run the executable file “RdiskDecrypt.exe”, and input username and password in dialog box. If they are correct, disk can be accessed and files can be copied. Username and password is required to access to the encrypted disk in every connection to PC. Note: Dividing one disk into two parts may erase the data in it.
  • Page 40 Please backup the data in disk before division. And merging two parts to one may also erase the data. Warning: Do not lose the user name and password you’ve input, otherwise you can not access to the encrypted disk and you have to merge the two parts to cancel the encrypted disk with files in it losing.
  • Page 41 Specification Dimension Weight LCM Window PC connection Flash memory Battery Record MP3、WMA、WMV、ASF FM radio Music format Working temperature Operating System Note: Product design and spec may change without notice. 24mm*24mm*24mm 64*48 USB2.0(FS) （Read: 1000K Byte, Write: 1000-900K Byte） 128M－256M Max Play time: 6 hours...
