Mercury IXA365i User Manual

Kobian ixa365i: user guide
Hide thumbs

Advertisement

Quick Links

Download this manual
Introduction
Thank you for purchasing the MP3 player. It is a
digital audio player. You do not need to carry a
cassette tape or CD anymore.
With the player, enjoying CD-quality music
becomes a breeze. You can store dozens of MP3
files in the built-in flash memory. Also, you can
listen to the radio or even record your favorite
radio program, an interview, conversation or
lecture.
The sound in this light shock-resistant player
will not skip or stretch at all. The file name and
MP3 track title are also conveniently displayed on
the LCD in the middle of the player for easy
reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the IXA365i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mercury IXA365i

Summary of Contents for Mercury IXA365i

  • Page 1 With the player, enjoying CD-quality music becomes a breeze. You can store dozens of MP3 files in the built-in flash memory. Also, you can listen to the radio or even record your favorite radio program, an interview, conversation or lecture.
  • Page 2 Accessories Stereo Earphone USB Cable Installation CD Manual 1 AAA battery System Requirements ■ Pentium 166 MHz, 32MB memory ■ 20MB hard disc space ■ USB 1.1 port ■ CD-ROM Drive 4X speed or above Microsoft Windows 98 / 98SE / 2000 / XP...
  • Page 3 Knowing your MP3 Player 128*64 pixels, OLED 5-ways Switch Press the 5-ways switch to enter MENU Dial the 5-ways switch up or down to increase or decrease the volume level Dial the 5-ways switch left or right to skip to previous or next track Dial and hold the 5-ways switch left or right to fast forward or reverse within the current track...
  • Page 4 player Hold switch Press the button to switch 5 play modes - Normal, Rock, Jazz, Classical and Pop Play / Pause / Power Button Press the button to power on the player, Playback or pause playback of music or voice files, Press and hold to power off the player REC / A-B Press and hold the button to record music or...
  • Page 5 Connecting to PC Power on your computer. Plug the flat USB connector of the USB cable we attached to a USB port of your computer. Plug the mini connector of the USB cable we attached to the player. The player will power on automatically. “Ready”...
  • Page 6 Function & Keys Instructions Play the Music When you press Play/Pause button, you will see the below pictures show the player in which play mode, music serial number/total number, playing time, music singer and name. At lowest row, it shows music name or ID3 information. When the player is in status of play and you press Play/Pause, the player will pause playback.
  • Page 7 To skip to previous or next track, please dial the 5-ways switch left or right (FF/REW). To power off the player, please press and hold Play/Pause for 3 seconds. When the player is in status of play or pause, you can dial the 5-ways switch up or down to increase or decrease the volume level.
  • Page 8 dial it left or right to choose sub-menu, then press it again to enter sub-menu as below. Select Music to go into playing mode of music. Select Voice to go into playing mode of recorded voice WAV files. In such status, you still can choose the corresponding function in the same menu.
  • Page 9 Select FM Tuner to enter radio interface. Select Setting to enter parameters setting menu. Select Delete File to enter files deleting interface.
  • Page 10 Select Information to enter information interface. Select Record to enter recording interface. FM Function Adjust frequency - Press the 5-ways switch to enter menu and dial it to select FM, then press the switch to enter Preset mode as below.
  • Page 11 The Preset mode – It sets 20 fixed channels. The first time you enter the mode, the player will search channels automatically. After searching, you can choose each channel by dial the switch left or right. The Manual mode – Press the switch to enter the interface as below.
  • Page 12 A-B button shortly. Then, the channel will be saved in the Preset mode for listening in the future. FM Radio Recording You can record FM programs as MP3 or WAV files. Press and hold the A-B button to enter recording interface as below.
  • Page 13 Press it again to keep recording. Press Play/Pause to stop recording and return to FM sub-menu. If you want to back to the Music or voice mode to listen to the files you recorded, please press and hold the 5-ways switch. Note: The volume control is still useful by dialing the 5-ways switch up or down.
  • Page 14 button to enter Rec Setting as below. Select Source to set the recording sources, microphone or FM. If you choose microphone, the voice or music will be recorded by built-in microphone from outside. If you choose FM, the voice or music will be recorded from FM programs.
  • Page 15 your needs. Recording Operation There are 2 ways to begin recording. 1. Recording by press and hold REC / A-B button – The recorded files will be named and saved automatically to Voice folder at root directory as M010.MP3 or V007.WAV. As below pictures, the LCD shows present LCD shows present recording time, left recording time and file name.
  • Page 16 file. 2. Press the 5-ways switch to enter menu and dial it to select Record, then press the switch to enter recording interface as below. To pause recording, please press the 5-ways switch. Press it again to keep on recording. Press Play/Pause button to stop recording.
  • Page 17 recorded file that you want to play by dialing the 5-ways switch left or right, then press Play/Pause button to play the WAV file. When you stop recording, you can press Play/Pause button to listen to the recorded file immediately. The playing picture is as below. If there are no recorded files or it’s the first time you enter the interface, No Files will be shown as below.
  • Page 18 To press the menu button, you can also enter the function menu to finish all selections and the settings. To press Play/Pause to stop the status of playing and back to Voice interface. Note: To play MP3 recorded files must under Music mode.
  • Page 19 2. Press the 5-ways switch to enter menu and dial it to select Setting, then press the switch to enter EQ sub-menu. It has 5 play modes – Normal, Rock, Jazz, Classical and Pop as below. If you don’t want to change the current setting, choose EXIT to quit the sub-menu.
  • Page 20 Set Repeat Mode Press the 5-ways switch to enter menu and dial it to select Setting, then press the switch to enter Repeat sub-menu. It has 5 repeat modes – Normal, Repeat Track, Repeat All, Shuffle, and Shuffle Repeat as below.
  • Page 21 Repeat Track: a certain piece of music plays loopy. Repeat All: all music play continuously and orderly until you do other operation. Shuffle: play at shuffle one music. Normal: All music plays orderly once and the player stops playing. Shuffle Repeat: all music plays at shuffle without order.
  • Page 22 press A-B to set the start point (A) and press it again to set the end point (B) as below. The player begins to play the repeated segment. To Press A-B or left/right to choose another music to cancel the loop function. Set Automatically Closing Time There are 5 times for optional to power off the player automatically.
  • Page 23 the switch to enter Auto Off sub-menu as below. Select Disable, the player will not close automatically. Select 1 Min, 2Mins, 5 Mins or 10Mins, the player will close automatically at the corresponding minutes under stop or pause mode. If you want to back to the Music mode, please press and hold the 5-ways switch.
  • Page 24 software we attached. Press the 5-ways switch to enter menu and dial it to select Delete, then press the switch to choose music or voice files that you want to delete as below. To choose music or voice files, you will enter the delete interfaces as below.
  • Page 25 If you don’t want to delete the current file, please choose NO to back to the sub-menu. Select the file you want to delete and choose YES to back to the sub-menu. Then you can continue deleting files. If you want to back to the Music mode, please press and hold the 5-ways switch.
  • Page 26 Note: If total volume and left volume are not shown on the LCD correctly, please format the player with the management software to insure the correct showing data. Display lyric Function Lyric files are of LRC format and they have the same name with the corresponding music files.
  • Page 27 Files Browser Function Choose FOLDER item and the file list is showed in the screen. You can choose each file with the left/right button in the wheel. Choose music file and press the MODE button, the menu will be popped out, as picture one: choose PLAY to play the music being chosen;...
  • Page 28 User Interface For the convenience of users, the player has 8 language items for users to choose. Whatever language you choose, the screen and ID3 information will show the corresponding language. For the convenience of users’ operation, the content of the English.
  • Page 29 Trouble Shooting Before using, we strongly suggest to install the management software first and format the player. In win98, please install the management software and connect the player to recognize device. During transferring process, the speed shown in the computer is faster different because of different OS, so the speed should be up the player.
  • Page 30 consumed. Please install a new battery. Q: After opening the player, no reaction when press buttons. A: The hold switch is locked. Unlock the switch and try it again. Q: After connecting, the mobile storage icon of the player can’t be found. A: You may not install the management software, or the application has be corrupted.
  • Page 31 Q: Up-plug the player brings out abnormity of the computer. A: It’s for the plugging or up-plugging of USB. In order to avoid the problem, we suggest don’t up-plug the USB while transferring. Q: The response of pressing button is slow and earphone doesn’t work normal.
  • Page 32 A: The player stores application and Chinese character library, so the memory shown is smaller than the actual. Q: Why do the preferences often lose? A: We often save preferences in Setting.dat. If you delete files or format the player, these preferences will lose, so you need to set again.
  • Page 33 Handleiding Accessories 1. De accesoires van uw MP3 speler Installatie CD Handleiding 2. Gebruik 2.1 Power aan / uit USB verleng kabel AAA batterij...
  • Page 34 Druk op de Play/Pause/Power knop. De ‘Power-aan’ afbeelding verschijnt Druk op de Play/Pause/Power knop en houd deze ingedrukt totdat bovenstaande afbeelding verschijnt en de voortgang indicatie verdwijnt. De MP3 speler is dan afgesloten. 2.2. ‘Hold’ funktie Beweeg de hold knop in de richting van de pijl. De Mp3 speler zal de hold afbeelding weergeven.
  • Page 35 Verbind de USB aansluiting van de MP3 speler met de aansluiting van uw PC. (De meegeleverde USB kabel kan hiervoor gebruikt worden). De bovenstaande afbeelding ‘connect’ zal verschijnen in uw MP3 speler. 2.4 Display 1. Afspeel status...
  • Page 36 2. Equalizer effect ‘3. loop’ status 4. Volume 5. ‘locked’ status 6. Batterij status 7. Herhaal teken 8. De actuele muziek 9. Afspeel tijd 10. Artiest Bestands naam 2.5 Afspelen van muziek Uw MP3 speler ondersteunt WMA/MP3 bestanden. Nadat de MP3 speler geactiveerd is, drukt u kort op de play/pause/power knop om bestanden af te spelen.
  • Page 37 2.6 FM Radio Uw Mp3 speler is geschikt om naar FM radio te luisteren. Druk kort op de menu knop om de radio functie in te schakelen. Duw de Menu knop naar links of rechts om een vorig of volgend station te kiezen.
  • Page 38 Om spraak op te nemen dient u op de A-B/REC knop te drukken. Houd deze ingedrukt om het signaal op te nemen. Druk op de Play/Pause/Power knop om te stoppen. Indien u herhaaldelijk naar hetzelfde bestand wilt...
  • Page 39 luisteren, drukt u éénmaal op de A-B knop tijdens afspelen om het begin te markeren. Druk nogmaals om het eindpunt te markeren. De MP3 speler zal het geselecteerde gedeelte herhaaldelijk afspelen. Tijdens het afspelen kunt u de A-B knop indrukken of een ander muziekbestand kiezen om het afspelen te beëindigen.
  • Page 40 het menu wilt verlaten dient u de menu knop langere tijd ingedrukt te houden. In het ‘bron’ menu kunt u kiezen uit: microfoon en FM. U kunt het formaat van de opname instellen op MP3 of WAV. De kwaliteit kan ingesteld worden op hoog, gemiddeld en laag.
