100305786_2000558371_Rev B
MODBUS AND BACNET
COMMUNICATION
INSTRUCTIONS
Armor Models: 1250 - 4000
Series: 100 & 101
Th is manual must only be used
WARNING
by a qualifi ed heating installer /
service
technician.
Read
all
instructions, including this manual,
the Installation and Operation
Manual, and the Service Manual,
before installing. Perform steps in
the order given. Failure to comply
could result in severe personal
injury, death, or substantial property
damage.
Save this manual for future reference.
