TC-900RG2 slim
TC-900RG2 slim
DIGITAL CONTROLLER FOR
REFRIGERATION AND DEFROST
Version 01
R
CONTROLS
DESCRIPTION
TC-900RG2 slim
The is a digital temperature
compressor, fan and defrost.
Application: Beverage freezers
TECHNICAL SPECIFICATIONS
- Power supply: 90~264Vac (50/60 Hz)
- Maximum load: FAN - 5(3)A / 250Vac 1/8HP - Fan output
DEFR - 10(3)A/ 250Vac 1/4HP - Defrost output
COMP - 1 6(8)A / 250Vac 1HP - Compressor output
- Sensors: S1 (Room)
S2 (Evaporator)
- Operation temperature: 0 to 50°C
- Humidity operation: 10 to 90% RH (without condensation)
PARAMETERS ALTERATION
Put the selector keys in the desired position and press the key for 10 seconds
until appear the indication
programmed for this function, use the key again to modify this value. After adjusted
the new value for the function wait 4 seconds. The controller will record the new
parameter and will pass to the function
the value of this function. Repite this for the functions
the next to be showed in the display to be configured. After the alteration of the
parameters the display comes to the indication of temperature.
OPERATION PARAMETERS
Item Parameters
P 1 Refrigeration time
P 2 D efrost time with the sensor of evaporator working
P 3 D efrost time with the sensor of evaporator damaged
P 4 Control temperature (setpoint)
Differential of control (hysteresis)
P 5
M inimum delay to restart the compressor
P 6
Low temperature or room sensor open
P 7
High temperature or room sensor in short circuit
P 8
Displacement of indication of room sensor (offset)
P 9
FUNCTIONING DESCRIPTION
Parameters v isualization
When the controller is energized, it will appear the parameters of configuration in the
following order:
REFRIGERATION TIME DEFROST TIME
Defrost on start
The controller will make defrost when energized if the temperature of the
sensor (S1) he will be below of 30 ºC and temperature of the sensor of the evaporator
(S2) below of 15 ºC.
Refrigeration
The compressor turns on and turns off by temperature, according the value adjusted
in the P4 parameter (see table above) during the refrigeration time (P1). After
elapsed the time the controller will initiate a defrost cycle (if the temperature of the
room sensor will be below of 30 ºC), turning off the compressor and the evaporator
fan. During the stage of refrigeration
compressor will be functioning .
Find manuals of all line on Web:
www.fullgauge.com
sales@fullgauge.com
support@fullgauge.com
Phone/Fax: +55 51 34753308
MADE IN BRAZIL
controller
. Release key and wait until appears the value
. Use the same procedure to modify
and
SETPOINT DIFFERENTIAL
evaporator fan remains turned on only while the
INDICATION DISPLACEMENT (OFFSET)
with outputs to
TC-900RG2 slim
The
in relation to the standard calibration. For this just press the key for 15 seconds until
appearing the indication
this function.
SIGNALLING
The luminous pointer in the frontal signals the status of the controller:
Led blinking
and fan ON. When the instrument is in refrigeration with the stopped indication led
blinks in a lesser frequency.
Led turned off
and the fan OFF.
Led turned on
fan OFF and the resist nces ON.
VISUAL ALARMS
Room sensor in short circuit or temperature above of P8
Room ensor
E vaporator
-30 ºC or above of
that will be
minutes.
KEY (ACCESS IN THE FRONT PANEL)
To change the refrigeration to defrost or vice-versa, just a simple touch on the key.To
visualize the temperature measured by the evaporator sensor (S2), keep pressed
the key for 5 seconds.
SELECTOR KEYS POSITION
0 0 0 1
1 0
12 hours 6 hours
6 hours 10
30 min. 30 min.
30 min.
10 min. 10 min.
10 min.
5.0 ºC -6.0 ºC -1.0 ºC
3.0 ºC 3.0 ºC 3.0 °C
120 sec. 120 sec.
120 sec. 120
-20 ºC -20 ºC
-20 ºC
45 ºC 45 ºC 45 °C
0.0 ºC 0.0 ºC 0.0 °C
Defrost
The defrost will be finished when the temperature in the evaporator (S2) reaches 15 ºC
or the temperature in the room (S1) reach 30 ºC . Otherwise, the defrost will be finished
after elapsed the maximum defrost time configured (P2 or P3). During the defrost the
last temperature measured in the refrigeration cycle will be frozen in the display. The
room
indication will be defrosted when this temperature be reached again or 15 minutes after
the end of the defrost.
Delay
When the instrument is energized or the temperature in the S1 sensor reaches the
setpoint (compressor turn off), the delay (P6) starts to be counted, preventing that the
compressor must be restarted in a period very short. Even than by temperature it wold
be necessary to turn on the compressor the delay (P6) is respected.
External selector
The external selector allows, with a combination of two keys, to define the functioning of
the controller with programmable presets.
allows adjustments of ±5.0°C in the room sensor (S1)
. Use the same procedure to modify the value of
The controller is in refrigeration mode, with the compressor
The controller is in refrigeration mode, with the compressor
The controller is in defrost
a
s opened or temperature below of P7
sensor damaged or temperature in the sensor below of
50 ºC. In this situation the duration of the thawing will be of 10
1 1
hours
Programmable parameter, indication
30 min.
Programmable parameter, indication
10 min.
2.0 ºC
Programmable parameter, indication
3.0 ºC
Programmable parameter, indication
sec.
-20 ºC
45 ºC
0.0 ºC Programmable parameter, indication
UL-Underwriters Laboratories
mode , with the compressor and
at display
at display
at display
at display
in the display
