EXAMPLE OF THE FINAL LOOK

STEP 3
Using the 2 mm Allen Key screw in the two (2) M4 x 4 Hexagonal
Socket Screws supplied with the Terminal Cover.
STEP 3
- 8 -
Be careful not to use excessive force when tightening
the screws as it is only necessary for the cover to remain
on the Terminal (Flow Indicator)!
