INSTALLING THE EK-QUANTUM VECTOR TERMINAL COVER
TERMINAL COVER
Milled markings to help
position the cover on
the terminal.
STEP 1
Carefully detach the terminal cover together with LEDs from the GPU
terminal. The latest EK water blocks come with no screws – all you
have to do is pull the cover away from the terminal.
STEP 1
STEP 2
Position the EK-Quantum Vector Terminal Cover on the Terminal
(Flow Indicator) of the water block with the help of milled markings
behind the front side.
STEP 2
- 6 -
EK-Quantum Vector Terminal Cover does not include any
LEDs. Detach the Terminal LED cable from the LED strip
as it is not needed. Be careful not to unplug the part of the
LED strip that illuminates the water block.
