NOTE: Before installing, configuring, operating, or maintaining Aparian products, please review this
information and the information located on
documentation, and installation files specific to your Aparian product.
INTRODUCTION
This manual describes the installation, operation, and diagnostics of the Aparian DH485 Router Series B. The DH485 Router/B provides intelligent data routing between EtherNet/IP and DH485 which can help
simplify the migration from MicroLogix and SLC systems to ControlLogix or CompactLogix platforms, where a DH485 interface is required. The DH485 Router/B can also be used to connect newer PanelView Plus
and PanelView 800 devices to a range of Rockwell Automation controllers. This is especially useful where newer PanelView Plus devices (supporting only Ethernet) are required to connect to controllers (new
and old) via DH485.
REQUIRED SOFTWARE
The DH485 Router/B requires Aparian Slate software to setup and configure. The software installation can be found at www.aparian.com/software/slate.
Document No. D120-018
www.aparian.com
for the latest software,
Page 1 of 4
Revision 1.4
02/2020
DH485 Router/B
Quick Start Guide
A-DH485R/B
Advertisement
Table of Contents
Related Manuals for APARIAN B Series
Summary of Contents for APARIAN B Series
- Page 1 INTRODUCTION This manual describes the installation, operation, and diagnostics of the Aparian DH485 Router Series B. The DH485 Router/B provides intelligent data routing between EtherNet/IP and DH485 which can help simplify the migration from MicroLogix and SLC systems to ControlLogix or CompactLogix platforms, where a DH485 interface is required. The DH485 Router/B can also be used to connect newer PanelView Plus and PanelView 800 devices to a range of Rockwell Automation controllers.
- Page 2 Revision 1.4 02/2020 MODULE INSTALLATION The module has two Ethernet ports located at the lower front of the module. There are also two ports at the bottom of the module for RS232/RS485 serial and power. The power port uses a three-way connector which is used for the DC power supply positive and negative (or ground) voltage as well as the earth connection.
- Page 3 ADDITIONAL INFORMATION The following resources contain additional information that can assist the user with the module installation and operation. Resource Link Slate Installation http://www.aparian.com/software/slate DH485 Router User Manual DH485 Router Datasheet http://www.aparian.com/products/dh485routerb Example Code & UDTs Document No. D120-018...
- Page 4 Technical support will be provided via the Web (in the form of user manuals, FAQ, datasheets etc.) to assist with installation, operation, and diagnostics. For additional support the user can use either of the following: Contact Us web link www.aparian.com/contact-us Support email support@aparian.com Document No.
