Idis DA-WM1100 Installation Manual

DA-WM1100 INSTALLATION MANUAL

Mounting

Mount the bracket to the wall as follows:
1
Insert cables from external devices, network and power
adapter through the hole in the rear of bracket.
2
Mount bracket to the wall by using the anchors and
screws.
3
Screw the plate to bracket by using the screws.
This manual is intended for users of the DA-WM1100 wall
mounting bracket. It includes instructions for mounting the DA-
WM1100 wall mounting bracket to a wall.
• This bracket is intended to be used with DC-D
series model of camera. Do not use it with other
models of cameras.
• This installation should be performed by a
qualified service personnel in conformance to all
local codes.
• You may need to reinforce the wall. If the wall is
not strong enough to support the camera, the
camera may fall.
• Do not use this product for other purposes.
Bracket
Bracket
Plate
