Klipsch R-5800-W Specifications

8" Two-Way In-Wall Loudspeaker
Creating a new benchmark in architectural
audio excellence, the installer-friendly
Klipsch R-5800-W in-wall loudspeaker
delivers a level of realism and subtlety that
surpasses and even intimidates competing
designs.
By featuring an 8-inch Cerametallic™
woofer cone, 1-inch titanium tweeter mated
to a pivoting Tractrix® Horn, as well as
treble and bass contour switches, there's no
denying this speaker's natural precision,
clarity and efficiency.
Available in a white finish, the R-5800-W can
be paired with one of Klipsch's new
installation kits (sold separately). Each of
these revolutionary kit designs allow for
increased mounting flexibility and
incorporate a mud ring, wire tie and
universal metal mesh wing for multi-position
placement and a color-coded bracket for
easy speaker size identification.
R-5800-W
Very high sensitivity and power handling
I
Pivoting Tractrix Horn compression driver tweeter for clear sound in
I
any location
Treble and midbass attenuation switches and IR receiver knock out
I
Single piece grille frame and rustproof aluminum grille
I
S P E C I F I C A T I O N S
FREQUENCY RESPONSE
SENSITIVITY
NOMINAL IMPEDANCE
CROSSOVER FREQUENCY
POWER HANDLING
ENCLOSURE MATERIAL/TYPE
DRIVE COMPONENTS
WIRE GAUGE ACCOMMODATED
WEIGHT
HEIGHT
WIDTH
MOUNTING DEPTH
CUTOUT DIMENSIONS
FINISH
INSTALLATION KIT
All specifications are subject to change without notice. ©2004
40Hz-20kHz ± 3dB
94dB @ 1 watt/1 meter
8 ohms
2600Hz
50 watts (200 watts peak)
ABS/ Infinite baffle, front flush with wall
Two-way system using one 1" (2.54cm)
titanium dome compression tweeter with a 6"
(15.24cm) square 90° x 60° pivoting
®
Tractrix Horn and one 8" (20.32cm)
aluminum cone woofer
12
7.9 lbs. (3.6kg)
16.1" (40.89cm)
10.6" (26.92cm)
3.75" (9.5cm)
14.75" (37.47cm) x 9.25" (23.50cm)
White
IK-800-W (sold separately)
www.klipsch.com
1-800-KLIPSCH
