Projecta SPM80K Operation Manual

Solar panel kits monocrystalline

Advertisement

Quick Links

12 VOLT
SOLAR PANEL KITS
MONOCRYSTALLINE

WARNING

SOLAR PANEL
• For installations with lead acid batteries, avoid sparks or flames near the batteries and
always use proper eye protection
• Given sufficient light, solar panels always generate energy even when they are disconnected
• Accidental 'shorting' of the terminals or wiring can result in sparks causing personal injury or a
fire hazard
• Do not scratch or bend solar panels
• Do not disassemble the solar panel
• When mounting solar panels at a height adhere to all relevant safety regulations
• Do not walk on modules
• Do not attempt to increase module output by concentrating light on its surface with mirrors
• Be sure to use components (cables, fuses, etc) greater than 25% of solar panel's maximum
current ratings
• When storing the Solar panel kit do not pack heavy items on top the Solar panel bag
• Do not disassemble the controller. Take to a qualified person if the unit requires repairing

FEATURE OVERVIEW

SOLAR PANEL
Compact and Powerful – Monocrystalline solar panels are manufactured from a solar cell that
is cast from silicon. These cells are more efficient at producing power than amorphous panels,
so the size of the panel is smaller yet produces greater output power
Lightweight, Foldable Design – Folds up into a self contained bag for easy storage
Scratch Resistant – Panels feature a scratch resistant mat coating for durability
5m Lead & Battery Clips – Fused battery lead makes for trouble free battery connection.
Front pocket for easy storage
Heavy Duty Canvas – Tough canvas material suitable for camping and off-road environments
Metal Support Legs – Legs keep the panels at the optimum angle for maximum performance
Collapsible Tent Pole – The pole feeds through the sewn in loops to keep the panel rigid
when set-up
Reinforced Eyelets – Reinforced eyelets allow you to secure the panels using tent pegs, or hang
the panels vertically
P/No. SPM80K, SPM120K
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPM80K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Projecta SPM80K

  • Page 1 P/No. SPM80K, SPM120K 12 VOLT SOLAR PANEL KITS MONOCRYSTALLINE WARNING SOLAR PANEL • For installations with lead acid batteries, avoid sparks or flames near the batteries and always use proper eye protection • Given sufficient light, solar panels always generate energy even when they are disconnected •...
  • Page 2 SPECIFICATIONS P/No. SPM80K SPM120K TYPE MONOCRYSTALLINE RATED POWER 120W OPEN CIRCUIT VOLTAGE SHORT CIRCUIT CURRENT 5.0A 7.52A PEAK POWER VOLTAGE 17.5V PEAK POWER CURRENT 4.56A 6.86A TEST CONDITIONS 1000W/m , 25˚C FUSE BATTERY CONNECTIONS Battery Clamps WEIGHT 4.7kg 6.8kg APPROVALS BATTERY SIZES 250–900CCA...
  • Page 3 BATTERY TYPE SELECTION Please check your battery manufacturer’s specifications to select correct battery type. The unit provides 4 battery types for selections: Gel, AGM, WET (conventional lead acid), and Calcium. There is a DIP switch at the back of the solar charge controller, this Dip switch is used for presetting your battery type.
  • Page 4 CHARGING STAGES Soft Charge (Level 1) – When batteries suffer an over-discharge, the controller will softly ramp the battery voltage up to 10V. Bulk Charge (Level 2) – Maximum current charging until batteries rise to Absorption level Absorption Charge (Level 3) – Constant voltage charging and battery is over 85%. Equalization Charge* (Level 4) –...
  • Page 5 SOLAR CONTROLLER SPECIFICATIONS Electrical Parameters 1-1-1 Rated solar panel amps – SPM80K Max. 1-1-2 Rated solar panel amps – SPM120K Max. Normal input Solar cell array voltage 15–22 Max. solar cell array voltage (output has no load) Max. The controller lowest operating voltage (at solar or battery side)
  • Page 6 INSTALLATION & CONNECTION STEP 1 Locate the panel in the best position Locate the panel in a position where it is exposed to the sun for the majority of the day. For Best results use a northern orientation. The panel will function in the horizontal or hung position, however for best performance tilt the panels so they directly face the sun.
  • Page 7 3 Lights Grand Total So the SPM80K solar panel kit produce 5.0 Amps an hour, this should be more than enough. You might find that during cloudy weather you will have to charge the battery by running your car for half an hour every second or third day.
  • Page 8 WARRANTY STATEMENT Applicable only to product sold in Australia Brown & Watson International Pty Ltd of 1500 Ferntree Gully Road, Knoxfield, Vic., telephone (03) 9730 6000, fax (03) 9730 6050, warrants that all products described in its current catalogue (save and except for all bulbs and lenses whether made of glass or some other substance) will under normal use and service be free of failures in material and workmanship for a period of one (1) year (unless this period has been extended as indicated elsewhere) from the date of the original purchase by the consumer as marked on the invoice.
