SOLAR PANEL KITS
WARNING
For installations with lead acid batteries, avoid sparks or flames near the batteries and
always use proper eye protection.
Given sufficient light, solar panels always generate energy even when they are disconnected.
Accidental 'shorting' of the terminals or wiring can result in sparks causing personal injury
or a fire hazard.
Do not scratch or bend solar panels.
Do not disassemble the solar panel frame.
When mounting solar panels at a height adhere to all relevant safety regulations.
For fixed installations ground the frame of the solar panel's to reduce lightning hazard.
Do not walk on modules.
Do not attempt to increase module output by concentrating light on its surface with mirrors.
Be sure to use components (cables, fuses, etc) greater than 25% of solar panel's maximum
current ratings.
When storing the Solar panel kit not do pack heavy items on top the Solar panel and bag.
FEATURES
Built in Solar Controller
Maintains your battery in a fully charged state while protecting it from over charge and solar discharge.
LED features
GREEN LED: Indicates fully charged
YELLOW LED: Indicates charging
Compact and Powerful
Polycrystalline solar panels are manufactured from a solar cell that is cast from silicon. These cells are more
efficient at producing power than an amorphous panels, so the size of the panel is smaller yet produces
greater output power.
Heavy Duty Frame
Corrosion resistant frames are constructed to withstand wind speeds in excess of 130 km/h in typical ground
mounted applications. The frames are clear anodized and the inner corner connection has a strong mechanical
resistance to weather.
P/No. SPP40K, SPP60K, SPP80K, SPP120K
1
