- Page 1 AX92325 2/4-port PCI Express 1 GigE PoE Card with M12 X-coded connector User’s Manual...
- Page 2 Disclaimers This manual has been carefully checked and believed to contain accurate information. Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or rights of any third party, or any liability arising from such use. Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document.
-
Page 3: Esd Precautions
◼ When handling boards and components, wear a grounding wrist strap available from most electronic component stores. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® Windows is a trademark of Microsoft Corporation. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. -
Page 4: Table Of Contents
Table of Contents Disclaimers ..................... ii ESD Precautions ................... iii Section 1 Introduction ..........1 General Description ................1 Features ....................1 Specifications ..................2 Dimensions ..................3 Section 2 Connectors & Jumper ......5 Connectors & Jumper ................. 5 2.1.1 External Voltage Input (ATX1) .............. -
Page 5: Introduction
30W of power at 54 VDC per port. It has a special design for the M12 connector that doesn't take up the space of other slots. With the support of PCIe x4 interface, the AX92325 can be easily integrated into Axiomtek’s diverse products including industrial PCs, ATX motherboards, embedded systems, etc. -
Page 6: Specifications
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector Specifications ⚫ Ethernet Port Intel® Ethernet Controller I210-AT 2 or 4 GbE LANs with Intel® i210-AT controller; ◼ supports 9.5KB jumbo frame and IEEE 1588 ⚫ PoE capability IEEE 802.3at compliant; each port delivers up to 30W at 54 VDC ◼... -
Page 7: Dimensions
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector Dimensions Component Side Solder Side Introduction... - Page 8 AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector This page is intentionally left blank. Introduction...
-
Page 9: Connectors & Jumper
Loose or improper connection might cause malfunctions. Make sure all connectors are properly and firmly connected. The following table lists the function of each connector on the AX92325. Connectors & Jumper... -
Page 10: 4-Pin Molex Male Connector (Atx2)
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector 2.1.2 4-pin Molex Male connector (ATX2) The power connector is used for the PoE function when the total power of the powered device is over 20 watts. The external power ATX2 is able to support max. 60 watts of PoE output. -
Page 11: Board Id (Jp1)
Note: You can ignore this setting if using only one piece of AX92325 on your system. When using two or more pieces of AX92325 on your system, you must set a different board ID for each card. Connectors & Jumper... - Page 12 AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector This page is intentionally left blank. Connectors & Jumper...
-
Page 13: Poe Manager Software
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector Section 3 PoE Manager Software Management software AMSIO PoE Manager is a highly integrated software management system that provides an easy-to-use application programming interface. Software Structure AMSIO PoE Manager is an intelligent software tool for managing PoE (Power over Ethernet) devices ranging from physical layer connectivity and communication layer protocols to middleware API and high-level software for management. -
Page 14: Amsio Poe Manager
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector AMSIO PoE Manager AMSIO PoE Manager is a software program that helps to monitor and manage PoE (Power over Ethernet) operations. The major task of PoE manager is to routinely monitor each PoE port’s power consumption and status. -
Page 15: Menu Bar
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector Menu Bar On the top of the main screen is the menu bar. Select a tab in this bar to go to the submenus. 3.3.1 File Polling rate Set the polling rate to monitor PoE power consumption and port status. Polling rates... -
Page 16: Side Menu
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector Side Menu The side menu is located on the left frame of the screen and contains all monitoring and control functions. It has two submenus: “Information” and “Control”. PoE Manager menu list Information The information menu includes the "General"... -
Page 17: Features
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector Features 3.5.1 Information General ⚫ General page Board ID: The board ID displays the board number and the module’s name. The user can click the drop-down list to display other module information. - Page 18 AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector Power Chart ⚫ PowerChart page Chart: The chart describes power consumption by each port and total amount of unused power. It uses percentage to represent ratio of each port.
-
Page 19: Control
AX92325 2/4-port PCI Express 1GigE PoE Card with M12 X-coded connector 3.5.2 Control Chip ⚫ Chip page Max Power Budget: This function shows the module’s max power budget value. The user cannot set power budget higher than max power budget limit.
