Side View
Height dimensions are shown with the leveling legs extended
to the minimum height of
The power cord is 66" (167.7 cm) long.
The water line attached to the back of the refrigerator is 78"
(198.1 cm) long.
A B
3 " (9.2 cm)
Model Size A
23' 68 "
(654 L) (174.6 cm)
25' 71 "
(694 L) (182.2 cm)
When leveling legs are fully extended to 1" (25 mm) below the
refrigerator, add " (19 mm) to the height dimensions.
" (6.35 mm) below the refrigerator.
"
21
(54.1 cm)
66"
(167.7 cm)
C
B C
68 " 68 "
(175.0 cm) (174.0 cm)
71 " 71 "
(182.5 cm) (181.6 cm)
Front View
35 "
(90.6 cm)
Model Size
23' (654 L)
25' (694 L)
A
3 "
(9.2 cm)
Height A
64 " (164.8 cm)
67 " (172.1 cm)
