Operating Instructions
Process pressure transmitter CPT-2x
Foundation Fieldbus
Ceramic measuring cell
Process pressure transmitter CPT-2x

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPT-2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WIKA CPT-2 Series

Summary of Contents for WIKA CPT-2 Series

  • Page 1 Operating Instructions Process pressure transmitter CPT-2x Foundation Fieldbus Ceramic measuring cell Process pressure transmitter CPT-2x...

  • Page 2: Table Of Contents

    Parameter adjustment - Extended adjustment..............33 Saving the parameterisation data ................... 44 Setup with PACTware ......................45 Parameter adjustment ....................45 Saving the parameterisation data ................... 45 Diagnosis, asset management and service ................ 46 Maintenance ........................46 WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 3 10.6 Trademark ........................80 Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions. Editing status: 2020-05-12 WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 4: About This Document

    The dot set in front indicates a list with no implied sequence. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 5: For Your Safety

    Arbi- trary conversions or modifications are explicitly forbidden. For safety reasons, only the accessory specified by the manufacturer must be used. To avoid any danger, the safety approval markings and safety tips on the device must also be observed. EU conformity The device fulfils the legal requirements of the applicable EU direc- tives. By affixing the CE marking, we confirm the conformity of the instrument with these directives. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 6: Namur Recommendations

    English language. Installations in the US shall comply with the relevant requirements of the National Electrical Code (ANSI/NFPA 70). Installations in Canada shall comply with the relevant requirements of the Canadian Electrical Code. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 7: Product Description

    Hardware from 1.0.0 • Software version from 1.2.0 Note: You can find the hardware and software version of the instrument as follows: • On the type plate of the electronics module • In the adjustment menu under "Info" Type label The type label contains the most important data for identification and use of the instrument: WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 8: Principle Of Operation

    Measured products are gases, vapours and liquids. Depending on the process fitting and measurement setup, measured products can be also viscous or contain abrasive substances. Measured variables The CPT-2x is suitable for the measurement of the following process variables: • Process pressure • Level WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 9 Depending on the adjusted damp- ing, these cause only slight and brief changes in the output signal. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 10 Additional, front seal for measuring cell Diaphragm Process fitting Seal for the process fitting Front-flush mounting with The front-flush installation is particularly suitable for applications with single seal viscous and abrasive media and in case of buildup. The measuring cell seal is positioned laterally. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 11 Fig. 7: Front-flush installation of the measuring cell with double seal (example: flange connection with extension) Measuring cell Seal for the measuring cell Process fitting Additional, front seal for measuring cell Diaphragm WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 12: Supplementary Cleaning Procedures

    To keep the purity level, the instruments are immediately packed in plastic foil after the cleaning process. The purity level remains as long as the instrument is kept in the closed original packaging. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 13: Packaging, Transport And Storage

    Technical data - Ambient conditions" • Relative humidity 20 … 85 % Lifting and carrying With instrument weights of more than 18 kg (39.68 lbs) suitable and approved equipment must be used for lifting and carrying. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 14: Mounting

    To maintain the housing protection, make sure that the housing lid is closed during operation and locked, if necessary. Screwing in Devices with threaded fitting are screwed into the process fitting with a suitable wrench via the hexagon. See chapter "Dimensions" for wrench size. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 15 Make sure that the upper temperature limits stated in chapter "Technical data" for the environment of the electronics hous- ing and connection cable are not exceeded. Fig. 10: Temperature ranges Process temperature Ambient temperature WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 16: Instructions For Oxygen Applications

    When quickly opening/closing the housing cover, the measured value can change for approx. 5 s by up to 15 mbar. For an effective ventilation, the filter element must be always free from buildup. In case of horizontal mounting, turn the housing so that the filter element points downward after the instrument is installed. This provides better protection against buildup. Caution: Do not use a high-pressure cleaner. The filter element could be dam- aged, which would allow moisture into the housing. The following paragraphs describe how the filter element is arranged in the different instrument versions. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 17 This provides better protection against buildup. Fig. 12: Position of the filter element - Ex-d version Rotatable metal ring Filter element Instruments with absolute pressure have a blind plug mounted instead of the filter element. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 18: Process Pressure Measurement

    Instruments with absolute pressure have a blind plug mounted instead of the filter element. Process pressure measurement Measurement setup in Keep the following in mind when setting up the measuring system: gases • Mount the instrument above the measuring point Possible condensation can then drain off into the process line. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 19 Siphon in U or circular form Pipeline A protective accumulation of water is formed through condensation in the pipe bends. Even in applications with hot steam, a medium temperature < 100 °C on the transmitter is ensured. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 20: Level Measurement

    Mount the instrument below the min. level • Do not mount the instrument close to the filling stream or emptying area • Mount the instrument so that it is protected against pressure shocks from the stirrer Fig. 18: Measurement setup for the level measurement WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 21: External Housing

    4 Mounting External housing Configuration Fig. 19: Configuration, process module, external housing Pipeline Process module Connection cable process assembly - External housing External housing Signal cable WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 22: Connecting To The Bus System

    In the case of instrument housings with self-sealing NPT threads, it is not possible to have the cable entries screwed in at the factory. The free openings for the cable glands are therefore covered with red dust protection caps as transport protection. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 23: Connecting

    6. Insert the wire ends into the terminals according to the wiring plan Note: Solid cores as well as flexible cores with wire end sleeves are insert- ed directly into the terminal openings. In case of flexible cores without end sleeves, press the terminal from above with a small screwdriver, the terminal opening is then free. When the screwdriver is released, the terminal closes again. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 24: Single Chamber Housing

    Simulation switch ("1" = mode for simulation release) For external display and adjustment unit Ground terminal for connection of the cable screening Double chamber housing The following illustrations apply to the non-Ex as well as to the Ex-ia version. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 25 Fig. 23: Connection compartment - double chamber housing Voltage supply, signal output For display and adjustment module or interface adapter For external display and adjustment unit Ground terminal for connection of the cable screening WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 26: Double Chamber Housing Ex D

    Housing IP66/IP68 (1 bar) Wire assignment, con- nection cable Fig. 26: Wire assignment in permanently connected connection cable Brown (+) and blue (-) to power supply or to the processing system Shielding WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 27: External Housing With Version Ip68 (25 Bar)

    External housing Electronics and connec- tion compartment for power supply 4...20mA 6 7 8 Fig. 28: Electronics and connection compartment Electronics module Cable gland for voltage supply Cable gland for connection cable, transmitter WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 28: Switch-On Phase

    After connecting the instrument to power supply or after a voltage recurrence, the instrument carries out a self-check: • Internal check of the electronics • Indication of a status message on the display or PC WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 29 5 Connecting to the bus system Then the actual measured value is output to the signal cable. The value takes into account settings that have already been carried out, e.g. default setting. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 30: Set Up With The Display And Adjustment Module

    The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 31: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 31: Adjustment System

    [OK] key: – Move to the menu overview – Confirm selected menu – Edit parameter – Save value • [->] key: – Change measured value presentation – Select list entry – Select menu items WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 32: Measured Value Indication

    "Language". Selection language In this menu item, you can select the national language for further parameterization. With the "[->]" button, you can select the requested language, with "OK" you confirm the selection and move to the main menu. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 33: Parameter Adjustment - Quick Setup

    Info: Instrument name, hardware and software version, date of manu- facture, device ID, sensor features Note: For optimum adjustment of the measuring point, the individual sub- menu items in the main menu item "Setup" should be selected one WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 34 In addition, the temperature unit of the instrument is specified. The selection determines the unit displayed in menu items "Peak value, temperature" and "in the variables of the digital output signal". Temperature unit: WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 35 0 % and 100 % must be carried out (adjustment). With the application "Level", the hydrostatic pressure, e.g. with full and empty vessel, is entered for adjustment. See following example: WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 36 Now select with [->] the menu item "Zero adjustment" and confirm with [OK]. 2. Edit the mbar value with [OK] and set the cursor to the requested position with [->]. 3. Set the requested mbar value with [+] and store with [OK]. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 37 3. Set the requested percentage value (e.g. 10 %) with [+] and save with [OK]. The cursor jumps now to the pressure value. 4. Enter the pressure value corresponding to the min. level (e.g. 0 mbar). WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 38 - and the indication or output of the volume is required. Corresponding linearization curves are preprogrammed for these vessels. They represent the correlation between the level per- centage and vessel volume. The linearization applies to the measured value indication and the current output. Lock/Unlock adjustment In the menu item "Lock/unlock adjustment" you safeguard the sensor parameters against unauthorized or unintentional modifications. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 39 In delivery status, the CPT-2x is set to English. Display value 1 and 2 In this menu item, you define which measured value is displayed. The default setting for the display value is "Lin. percent". Display format 1 and 2 In this menu item you define the number of decimal positions with which the measured value is displayed. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 40 In another window you can carry out a reset of the two peak values separately. Simulation In this menu item you simulate measured values. Hence, the signal path can be tested via the bus system to the input card of the control system. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 41 The following table shows the default values of the instrument. De- pending on the instrument version or application, all menu items may not be available or some may be differently assigned: WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 42 Actual measured value Temperature Actual temperature values from measuring cell, elec- tronics Simulation Process pressure Additional adjustments Menu item Parameter Default value 0000 Date/Time Actual date/Actual time Copy instrument settings Special parameters No reset WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 43 Change the settings of the special parameters only after having con- tacted our service staff. 6.5.5 Info Device name In this menu item, you can read out the instrument name and the instrument serial number: WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 44: Saving The Parameterisation Data

    In the display and adjust- If the instrument is equipped with a display and adjustment module, ment module the parameter adjustment data can be saved therein. The procedure is described in menu item "Copy device settings". WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 45: Setup With Pactware

    Internet. Saving the parameterisation data We recommend documenting or saving the parameterisation data via PACTware. That way the data are available for multiple use or service purposes. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 46: Diagnosis, Asset Management And Service

    1. Loosen compression nut and remove the pressure transmitter from the welded socket 2. Remove the O-ring seal for the process fitting 3. Clean the diaphragm with brass brush and cleaning detergent 4. Loosen the hexagon and remove the process component from the process fitting WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 47: Diagnosis Memory

    • Switch-on and switch-off times • Status messages (according to NE 107) • Error messages (according to NE 107) The data are read out via a PC with PACTware/DTM or the control system with EDD. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 48: Asset Management Function

    Failure Code Cause Rectification DevSpec Text message Diagnosis Bits F013 Gauge pressure or low pressure Exchange measuring cell Bit 0 No valid measured value Measuring cell defective Send instrument for repair available WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 49 Sensor no longer carries out a Carry out a reset Bit 11 measurement Measurement function Disconnect operating voltage disturbed briefly Tab. 5: Error codes and text messages, information on causes as well as corrective measures WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 50: Rectify Faults

    Tab. 8: Error codes and text messages, information on causes as well as corrective measures Rectify faults Reaction when malfunc- The operator of the system is responsible for taking suitable meas- tion occurs ures to rectify faults. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 51: Exchange Process Module On Version Ip68 (25 Bar)

    During exchange, protect the inner side of the parts against contami- nation and moisture. Proceed as follows when carrying out the exchange: 1. Losen the fixing screw with the hexagon key wrench 2. Carefully detach the cable assembly from the process module WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 52: Instrument Repair

    Complete one form for each instrument • If necessary, state a contamination • Clean the instrument and pack it damage-proof • Attach the completed form and possibly also a safety data sheet to the instrument WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 53: Dismount

    Pass the instrument directly on to a specialised recycling company and do not use the municipal collecting points. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 54: Supplement

    Ʋ Seal below wall mounting plate EPDM Ʋ Inspection window housing cover Polycarbonate (UL-746-C listed) Ground terminal 316Ti/316L Glass with Aluminium and stainless steel precision casting housing Only for 316L with 3A approval WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 55 0 … +1 bar/0 … +100 kPa +35 bar/+3500 kPa -1 bar/-100 kPa Between transmitter and external electronics housing. Fix connected to the sensor. Data on overload capability apply for reference temperature. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 56 Nominal measuring ranges and overload capacity in psi Nominal range Overload capability Maximum pressure Minimum pressure Gauge pressure 0 … +0.4 psig (only for measuring cell ø 28 mm) +75 psig -0.7 psig 0 … +1.5 psig +225 psig -3 psig 0 … +5 psig +375 psig -11.50 psig WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 57 -10 … 110 % Ʋ Pressure value -20 … 120 % Zero/Span adjustment: Ʋ Zero -20 … +95 % Ʋ Span -120 … +120 % Ʋ Difference between zero and span max. 120 % of the nominal range WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 58 Rise time (10 … 90 %) ≤ 55 ms ≤ 150 ms Step response time (ti: 0 s, 10 … 90 %) ≤ 80 ms ≤ 200 ms Damping (63 % of the input variable) 0 … 999 s, adjustable via menu item "Damping" WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 59 4 … 20 mA and refers to the set span. Turn down (TD) is the ratio "nominal measuring range/set span". The thermal change of the zero signal and output span corresponds to the temperature error F chapter "Calculation of the total deviation (according to DIN 16086)". Basic temperature error F WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 60 TD 10 : 1 TD 20 : 1 Factor FTD 1.75 10.5 Long-term stability (according to DIN 16086) Applies to the respective digital signal output (e.g. HART, Profibus PA) as well as to analogue cur- rent output 4 … 20 mA under reference conditions. Specifications refer to the set span. Turn down (TD) is the ratio nominal measuring range/set span. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 61 -15 … +150 °C (5 … +302 °F) Perlast G92E -15 … +130 °C (-4 … +266 °F) -15 … +150 °C (5 … +302 °F) Chemraz 535 -30 … +130 °C (-22 … +266 °F) without process fitting G½ (ISO 228-1) With process fitting PVDF, process temperature max. 100 °C (212 °F). Measuring cell ø 28 mm WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 62 Mechanical stress Vibration resistance 4 g at 5 … 200 Hz according to EN 60068-2-6 (vibration with resonance) Shock resistance 50 g, 2.3 ms according to EN 60068-2-27 (mechanical shock) Depending on the instrument version. 2 g with housing version stainless steel double chamber WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 63 Adjustment elements Ʋ 4 keys [OK], [->], [+], [ESC] Protection rating Ʋ unassembled IP20 Ʋ Mounted in the housing without lid IP40 Materials Ʋ Housing IP66/IP68 (0.2 bar), only with absolute pressure. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 64 Power supply by/max. number of sensors Fieldbus/32 Potential connections and electrical separating measures in the instrument Electronics Not non-floating Reference voltage 500 V AC Conductive connection Between ground terminal and metallic process fitting Galvanic separation between electronics and metal housing parts WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 65: Device Communication Foundation Fieldbus

    The following table gives you an overview of the instrument versions and the corresponding device descriptions, the electrical characteristics of the bus system as well as the applied function blocks. Protection rating IP66/IP68 (0.2 bar) only in conjunction with absolute pressure. When used with fulfilled housing protection. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 66: Calculation Of The Total Deviation

    10.3 Calculation of the total deviation The total deviation of a pressure transmitter indicates the maximum measurement error to be ex- pected in practice. It is also called maximum practical deviation or operational error. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 67: Practical Example

    Pressure measurement in the pipeline 4 bar (400 KPa) Product temperature up to 50 °C CPT-2x with measuring range 10 bar, deviation < 0.2 %, process fitting G1½ (measuring cell ø 28 mm) 1. Calculation of the Turn down TD = 10 bar/4 bar, TD = 2.5 : 1 WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 68 0.1 % < 0.1 % < 0.02 % x TD 0.2 % < 0.2 % < 0.04 % x TD Tab. 24: Determination of the deviation from table: F = 0.2 % WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 69 The total deviation of the measurement is hence 0.94 %. Deviation in bar: 0.94 % of 4 bar = 0.038 bar The example shows that the measurement error in practice can be considerably higher than the basic deviation. Reasons are temperature influence and Turn down. WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 70: Dimensions

    ½ NPT M20x1,5/ ½ NPT Fig. 44: Housing versions in protection IP66/IP67 (with integrated display and adjustment module the housing is 9 mm/0.35 in higher) Aluminium - single chamber Aluminium - double chamber WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 71 Fig. 46: Housing versions in protection IP66/IP67 (with integrated display and adjustment module the housing is 9 mm/0.35 in higher) Stainless steel single chamber (electropolished) Stainless steel single chamber (precision casting) Stainless steel double chamber housing (precision casting) WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 72 ø 80 mm (3.15") M20x1,5/ ½ NPT Fig. 48: Housing version with protection rating IP69K (with integrated display and adjustment module the housing is 9 mm/0.35 in higher) Stainless steel single chamber (electropolished) WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 73 (2.76") 8 mm (0.12") (0.32") 110 mm x 90 mm (4.33" x 3.54") Fig. 49: IP68 version with external housing Lateral cable outlet Cable outlet axial Plastic housing Stainless steel housing, electropolished WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 74 G½ manometer connection (EN 837) volume-reduced ½ NPT inside ¼ NPT M20 x 1.5 manometer connection (EN 837) Notes: For the version with "Second Line of Defense", the measure of length increases by 17 mm (0.67 in). WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 75 For the version with temperature range up to 150 °C/302 °F, the measure of length increases by 28 mm (1.1 in). For the version with "Second Line of Defense", the measure of length increases by 17 mm (0.67 in). WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 76 For the version with temperature range up to 150 °C/302 °F, the measure of length increases by 28 mm (1.1 in). For the version with "Second Line of Defense", the measure of length increases by 17 mm (0.67 in). WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 77 For the version with temperature range up to 150 °C/302 °F, the measure of length increases by 28 mm (1.1 in). For the version with "Second Line of Defense", the measure of length increases by 17 mm (0.67 in). WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 78 For the version with temperature range up to 150 °C/302 °F, the measure of length increases by 28 mm (1.1 in). For the version with "Second Line of Defense", the measure of length increases by 17 mm (0.67 in). WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 79 For the version with temperature range up to 150 °C/302 °F, the measure of length increases by 28 mm (1.1 in). For the version with "Second Line of Defense", the measure of length increases by 17 mm (0.67 in). WIKA Operating Instructions - Process pressure transmitter CPT-2x...

  • Page 80: Trademark

    10 Supplement 10.6 Trademark All the brands as well as trade and company names used are property of their lawful proprietor/ originator. WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 81 Measurement setup 18, 19, 20 NAMUR NE 107 48 Oxygen applications 16 Parameterization example 35 Peak value indicator 40 Position correction 35 Pressure compensation 18 – Ex d 17 – Standard 17 Process pressure measurement 19 WIKA Operating Instructions - Process pressure transmitter CPT-2x...
  • Page 82 Notes WIKA Operating Instructions - Process pressure transmitter CPT-2x...
