Summary of Contents for HOMCLOUD Speed 11S
- Page 1 Speed 11S CAMERA ORIGINALITY DESIGN SMART - AND BEAUTIFUL QUICK GUIDE...
-
Page 2: What's In The Box
What's in the box Please consult this checklist for all parts. Speed 11S Bracket EU Power adapter Screws User manual Wrench... - Page 3 Description Antenna Reset SD card slot Microphone Speaker Lens Status light IR LED Screw Power DC 12V/1A Microphone Capture sound for your video Status light Solid red light on: network is malfunctional Blinking red light: wait for network connection (slowly blinking) connecting the network (quickly blinking) Solid blue light on: the camera is working correctly Support local SD card storage (Max.128G)
-
Page 4: Installation
Installation Bracket Installation -75°~75° 0~90° After fixing your camera, please lock this screw When ajusting your camera angle, please lock this screw (Optional) 1. Fix the bracket on the wall 2. Install the camera in the bracket and lock it with the screw... - Page 5 Connection Set up router The router supports the 2.4GHz WiFi (doesn't support the 5GHz), and is connected to the WiFi network.Please set the parameters of the router before connecting the WiFi network, and record the SSID and password of your WiFi. Please keep network available 2.4GHz 5GHz...
- Page 6 Open the Homcloud App, click "My" >> "Home Management" >> "Create a home", and you can customize the home name and related settings (optional). Click "Add Device" or "+", and then select “Speed 11S Security cam” or any other "Smart Camera" icons to add camera.
- Page 7 QR Code Configuration Power on and reset camera until the status indicator is flashing quickly or a prompt tone is heard, and then click "Next". Then input your WiFi's passwords and click "Next". Click " " to change network. Note: 1) Camera only supports 2.4GHz WiFi network.
- Page 8 QR Code Configuration In this interface, you should scan the QR code in your phone with the camera,when the camera comes out "dong dong dong". And you can complete the configuration about 30s.
- Page 9 QR Code Configuration When connecting, you should make sure your router,mobile,and camera are as close as possible.When camera added successffully,click " " you could also DIY the camera's name. Icons Enlarge the image full screen. Turn on receiving audio. Switch to Full HD resolution (SD is Standard Resolution). Take a snapshot (it will be saved on your smartphone).
- Page 10 In "Smart Camera" interface,click " ",you can set the camera common functions. - Waterproof grade: IP65 - Homcloud code: ME-WCS11SPT - Working temp: -20°C - 50°C - Model No: Speed 11S - View Angle: 110° - Power: DC 12V1A - Dimension: 180x75x100mm - Resolution: 2Mp, 1920(H)*1080(V)
- Page 11 Functions Pan/Tilt You can rotate the camera horizontally by the App on your smartphone, and adjust vertical angle manually, so that you can get a wide vision. Video flip Flip your video stream up or down for maximum flexibility. Motion detection The camera can detect movements, and then send you push notifications and app alerts.
-
Page 12: Google Assistant
Google Assistant... - Page 13 Chromecast...
-
Page 14: Amazon Alexa
Amazon Alexa... - Page 15 Directive 2014/53 / EU of the European Parliament and of the Advice. The declaration can be consulted on the website www.homcloud.com/doc. "Homcloud" is a registered trademark of Life365 Italy S.p.A. Imported by: Life365 Italy S.p.A. - European General Agency Viale Roma 49/a, 47122 Forli, Italy - Made in China...
