KitchenAid Architect Series II KHMS2056S Dimension Manual

Above-the-counter microwave oven
Hide thumbs


Advertisement

PRODUCT MODEL NUMBERS
KHMS2056S
Electrical: A 120-volt, 60-Hz, AC-only, 15- or
20-amp electrical supply located in the upper
cabinet as close as possible to the microwave
oven. A time-delay fuse or circuit breaker and
separate circuit is recommended.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
®
Above-the-Counter Microwave Oven
OVERALL DIMENSIONS
CABINET OPENING DIMENSIONS
*33" (83.2 cm) is typical for 69" (175.3 cm) installation height.
A
33" (83.2 cm)
typical*
69" (175.3 cm) min.
A. 2" x 4" wall stud
B. Grounded 3 prong outlet
Exact dimension may vary depending on type of range/cooktop
below.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
B
36"
(91.4 cm)
min.
12" (30.5 cm) min.
13" (33.0 cm) max.
Ref. W10189719
04-18-08
