Lennox DOAS DLV Installation Instructions Manual

Figure 1.1 – Extended Vent Kit Installed
(C-Cabinet, Non-Condensing Heat Option Shown)
WARNING
1. Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, injury or death, and could cause
exposure to substances which have been
determined by various state agencies to cause
cancer, birth defects or other reproductive harm.
Read the installation, operating and maintenance
instructions thoroughly before installing or
servicing this equipment.
2. Disconnect power supply before making wiring
connections to prevent electrical shock and
equipment damage.
CAUTION
As with any mechnical equipment, personal injury
can result from contact with sharp sheet metal
edges. Be careful when you handle this equipment.
PLEASE BE SURE TO LEAVE IT WITH THE OWNER WHEN YOU LEAVE THE JOB.
Extended Vent Kit for Gas-Fired Furnace Options
Packaged Ventilation/Dedicated Outside Air System (DOAS)
THIS MANUAL IS THE PROPERTY OF THE OWNER.
LNX15-574.2
INSTALLATION INSTRUCTIONS
IMPORTANT
1. The use of this manual is specifically intended
for a qualified installation and service agency.
All installation and service of these kits must be
performed by a qualified installation and service
agency.
2. These instructions must also be used in
conjunction with the Installation and Service
Manual originally shipped with the appliance, in
addition to any other accompanying component
supplier literature.
3. Modifications to the kit may result in poor
performance or nuisance alarms. Do not change
the contents of the kit or deviate from these
instructions.
Application
For units with optional gas furnaces (Model Digit 17=2, 3, 5,
or 6), the standard power exhauster discharge configuration is
a horizontal exhaust cover for non-condensing (81% efficient)
furnaces and a downturn elbow for condensing (90%+ efficient)
furnaces. In certain installations, such as close proximity to
adjacent equipment or parapet walls, it is desirable to redirect
the products of combustion vertically through an extended vent
kit that terminates above the top of the unit as shown in Figure
1.1. Agency approved extended vent kits are available for field
installation as detailed on the following pages.
LNX15-574.2
5H0864980002
August, 2021
model DLV
1
