NORTEK GLOBAL HVAC, LLC
Please read this owner's manual carefully before operation and retain for future reference.
If you have lost the owner's manual, please visit www.NortekHVAC.com for electronic version.
Wired Remote Controller WRC3 and
Wireless Remote Controller WLRC3
Owner's Manual
Commercial Air Conditioners
Advertisement
Table of Contents
Related Manuals for Nortek WRC3
Summary of Contents for Nortek WRC3
- Page 1 NORTEK GLOBAL HVAC, LLC Wired Remote Controller WRC3 and Wireless Remote Controller WLRC3 Owner's Manual Commercial Air Conditioners Please read this owner's manual carefully before operation and retain for future reference. If you have lost the owner’s manual, please visit www.NortekHVAC.com for electronic version.
- Page 2 User Notice Do not throw, drop, or mishandle remote controller. Do not operate remote controller with wet hands. Please read the manual carefully before using and installing this product. Children and persons with reduced mental, sensory or physical capabilities should not be allowed to operate or maintain this equipment.
-
Page 3: Table Of Contents
Contents Wired Remote Controller WRC3 ..............1 1 Symbols on LCD ................... 1 1.1 Outside View of the Wired Remote Controller ............1 1.2 LCD of the Wired Remote Controller ..............1 2 Buttons ......................2 2.1 Buttons on the Wired Remote Controller .............. 2 .................. -
Page 4: Wired Remote Controller Wrc3
Wired Remote Controller WRC3 Wired Remote Controller WRC3 1 Symbols on LCD 1.1 Outside View of the Wired Remote Controller AUTO TURBO HOUR SHIELD MEMORY MASTER SAVE QUIET E-HEATER BLOW Mode Enter/Cancel Enter/cancel Function Timer On/Off 1.2 LCD of the Wired Remote Controller... -
Page 5: Buttons
Wired Remote Controller WRC3 Symbols Description Sleep function (Only sleep 1). Gate-control function (this function is yet unavailable for this unit). Lock function. Shield functions (buttons, temperature, On/Off or Mode is shielded by the remote monitor. after power failure and then power recovery). - Page 6 Wired Remote Controller WRC3 Name Enter/Cancel Mode /Save/E-heater/Blow etc. On/Off Press and hold for 5s under off state of the unit to Enter/Cancel the Memory function(If memory is set, indoor unit after power failure and then power faulted to be off after power recovery. Memory off is default before delivery.).
-
Page 7: Operation Instructions
Wired Remote Controller WRC3 3 Operation Instructions 3.1 On/Off Press On/Off to turn on the unit and turn it off by another press. AUTO Enter/Cancel Mode Enter/Cancel Mode Function Timer Function Timer On/Off On/Off Auto Cooling Heating the temperature will be increased or decreased by 1... - Page 8 Wired Remote Controller WRC3 AUTO Enter/Cancel Mode Function Timer On/Off Middle High AUTO Mode Enter/Cancel Function Timer On/Off...
- Page 9 Wired Remote Controller WRC3 AUTO AUTO AUTO HOUR HOUR Enter/Cancel Mode Enter/Cancel Mode Enter/Cancel Mode Function Timer On/Off Function Timer Function Timer On/Off On/Off Press “Increase”or “Decrease” Turn on the unit,without setting timer Press “Timer”button to set button to adjust time...
- Page 10 Wired Remote Controller WRC3 with Enter/Cancel Mode Enter/Cancel Mode Enter/Cancel Mode Function Timer On/Off Function Timer On/Off Function Timer On/Off Turn on the unit,without turning on Press “ Function ”button into swing state Press “Enter/Cancel” to confirm swing function Enter/Cancel...
- Page 11 Wired Remote Controller WRC3 interface. After that, press Enter/Cancel to cancel this function. after the unit runs under Sleep 1 for 1hr and 1 after another 1hr. After that, the unit will run at this temperature. after the unit runs under Sleep 1 for 1hr and 1 after another 1hr.
- Page 12 Wired Remote Controller WRC3 desired temperature. then press Enter/Cancel to cancel this function. TURBO TURBO Enter/cancel Mode Enter/cancel Mode Enter/cancel Mode Function Timer On/Off Function Timer On/Off Function Timer On/Off Press “Enter/cancel”to turn on Turn on the unit,without turning on turbo Press“...
- Page 13 Wired Remote Controller WRC3 will be turned on automatically. Enter/Cancel to cancel this function. and then press Enter/Cancel to turn it on. E-HEATER E-HEATER Enter/Cancel Mode Enter/Cancel Mode Enter/Cancel Mode Function Timer On/Off Function Timer On/Off Function Timer On/Off Auxiliary electric heating function Press “...
- Page 14 Wired Remote Controller WRC3 Blow function: After unit cycles off, the blower will continue to run for 2 minutes to evaporate then press Enter/Cancel to active this function. press Enter/Cancel to cancel this function. AUTO AUTO AUTO BLOW BLOW Enter/Cancel...
- Page 15 Wired Remote Controller WRC3 (1). Lock at the same time for 5s till the wired remote controller enters the Lock function. In this case, LCD displays . After that, repress these two buttons at the same time for 5s to quit this function.
-
Page 16: Installation And Dismantlement
Wired Remote Controller WRC3 4 Installation and Dismantlement Open the cover of the electric control box of the indoor unit. PCB. be up to 20 meters ( the standard distance is 8 meters) 4.2 Installation of the Wired Remote Controller... - Page 17 Wired Remote Controller WRC3 (1). Prior to the installation, please turn off power supply to the wired controller. (2). (3). Stick the soleplate of the wired remote controller to the wall over the installation hole and (4). Insert the four-core twisted pair line into the slot of the wired remote controller and then (5).
-
Page 18: Dismantlement Of The Wired Remote Controller
Wired Remote Controller WRC3 cord and connection lines between the indoor and outdoor unit, with a minimum interval of 20cm. 4.3 Dismantlement of the Wired Remote Controller 5 Errors Display Note: In event of any error, please turn off the unit and contact the professionally skilled personnel. - Page 19 Wired Remote Controller WRC3 Error Error Error Error Code Code Return air temperature sensor open/short Drive board communication error circuited Evaporator temperature sensor open/short circuited Indoor unit liquid valve temperature sensor Indoor and outdoor units unmatched open/short circuited Communication line misconnected or...
-
Page 20: Wireless Remote Controller Wlrc3
Wireless Remote Controller WLRC3 Wireless Remote Controller WLRC3 Notes: Be sure that there are no obstructions between the receiver and the remote controller; Do not drop or throw the remote controller; Do not let any liquid into the remote controller or expose the remote controller to direct Press this button to turn on/off the unit. - Page 21 Wireless Remote Controller WLRC3 3) SLEEP is Sleep Off. After the unit is turned off, the Sleep function is canceled. When the sleep function is set already, the symbol and Auto modes, this function is not available. Auto Low Speed Medium Speed 5) CLOCK for more than 2 seconds, the value on ten’s place will increase by 1 in every 0.5 seconds.
-
Page 22: Guide For General Operation
Wireless Remote Controller WLRC3 , the indoor ambient temperature will temperature. 12) SWING UP/DOWN ( the same as that of at the current position. 13) AIR ( within 5 seconds. Each press will make the time increased or decreased by 1 controller and the remote controller will send the temperature information to the main controller every 10 minutes. -
Page 23: Guide For Optional Operation
Wireless Remote Controller WLRC3 3 Guide for Optional Operation unit is stopped to avoid mould. stopped completely. Under the Heat mode or Auto Heat mode, if the unit is turned off, the compressor and outdoor stop completely. that the ambient temperature will approaches the preset temperature as soon as possible.
