Periodic maintenance and adjustment
Removing and installing the
cowling and panels
The cowling and panels shown need to
be removed to perform some of the
maintenance jobs described in this
chapter. Refer to this section each time
the cowling or a panel needs to be re-
moved and installed.
3 2
7
ZAUE3509
1. Panel A
2. Panel B
3. Panel C
4. Cowling A
Cowling
To remove the cowling
1. Remove panels A and B. (See
page 7-7.)
2. Remove the bolts, quick fasteners
EAU18724
and screw, and then pull the cowl-
ing outward and take it off.
1
2
ZAUE3528
1. Cowling A
2. Bolt
3. Quick fastener
4. Screw
3. Disconnect the turn signal light
4
lead and unhook from cowling.
EAUE3441
ZAUE3379
1. Turn signal light lead
To install the cowling
1. Connect and place the turn signal
2. Fit the projection on the cowling
1
3
4
3
ZAUE3380
1. Cowling A
2. Projection
3. Hole
3. Install the screw, quick fasteners
4. Install panels A and B. (See page
1
7-7
light leads on it's original position.
into the hole, and then push the
cowling inward.
3 3
2 2
1
and bolts.
7-7.)
