Home
Print preview This option allows you to preview the selected job.
Folder OK
Folder
warning
Folder fault
Menus
Select job
Counts
Print adjust
Settings
Diagnostics
Information or
Statistics
Files
Service
Version
Information
Instruction manual
13

Description of icons

This option will return you to the Home screen.
This indicates that there are no faults or warnings
active.
This indicates that there is one or more warnings
active.
This indicates that there is one or more Fault
messages active.
This option allows you to access the menu options.
This option allows you to select a job to be printed.
This option allows you to view the various printer
counts.
This option allows you to configure the basic print
settings.
This option allows access to the printer settings
menus.
This option allows access to the various diagnostics
functions.
This option allows you to view the selected Image
field information or statistical details.
This option allows you to manage the various
Database files.
This option allows access to the Service menu.
This is password protected.
This option allows you to view specific information
about the printer.
