June 8, 2016
2017 MDX: TQI and New Model Service Information
AFFECTED VEHICLES
Year
Model
2017
MDX
MDX
With Technology Package
With Technology and Entertainment Packages
With Advance Package
With Advance and Entertainment Packages
INTRODUCTION
This bulletin covers the total quality inspection (TQI) of the 2017 MDX. It includes these procedures:
1.
Remove the Exterior Protective Coatings
2.
Install the Fuses
3.
Remove the Interior Protective Coverings
4.
Install the Floor Mats
5.
Check the Battery
6.
Install the Body Plugs
7.
Install the Front License Plate Holder
8.
Set the Tire Pressures
9.
Do the PCM Idle Learn Procedure
10.
Initialize the Audio-Navigation Unit Anti-Theft
Function and Set the AM/FM Audio Unit
Presets
To do a TQI on a model with a navigation system, be sure to complete S/B 16-027, 2017 MDX: TQI of the Navigation
System.
CLIENT INFORMATION:
training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and you should not assume
this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an
authorized Acura automobile dealer.
© 2016 American Honda Motor Co., Inc. – All Rights Reserved
Service Bulletin
2WD
The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and
Trim Level
MDX
With Technology Package
With Technology and Entertainment Packages
With Advance Package
With Advance and Entertainment Packages
11.
Set the Clock
12.
Set the Compass Zone (Models Without Navigation)
13.
Check the Compass Calibration (Models Without
Navigation)
14.
Check/Refresh SiriusXM
Service (Except in Alaska and Hawaii)
15.
Check the ACC, Collision Mitigation Braking
™
System
/Forward Collision Warning, LKAS, Lane
Departure Warning/Road Departure Mitigation, and
Auto Idle Stop Indicators (If Equipped)
16.
Check the Head-Up Warning (HUW) Indicator
(If Equipped)
®
17.
Check Bluetooth
18.
Check the Moonroof One-Touch Feature
19.
Reset the AcuraLink Control Unit
20.
Set Up the Rear Entertainment System
(If Equipped)
16-026
®
SH-AWD
®
Radio Dealer Demo
®
HandsFreeLink
(HFL)
04105 Version 1
Page 1 of 13

Advertisement

loading
Need help?

Need help?

Do you have a question about the MDX 2017 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acura MDX 2017

Summary of Contents for Acura MDX 2017

  • Page 1 These procedures should not be attempted by “do-it-yourselfers,” and you should not assume this bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an authorized Acura automobile dealer. Page 1 of 13...
  • Page 2 This bulletin also includes this new model service information: Heated Windshield (Advance Models) Real Wood Surfaces (Advance Models ) Auto High Beams (Technology Models and Charge and Data Ports Above) Surround View Camera (Advance Models) Capless Fuel System Walk-Away Auto Lock Electric Parking Brake (EPB) Power Folding Mirrors (Technology Models and Automatic Brake Hold System...
  • Page 3 2. When the indicator blinks, touch the keyless remote to the ENGINE START/STOP button. The indicator will switch from blinking to steady when communication is complete. 3. Start the engine by pressing the ENGINE START/STOP button while pressing the brake pedal. You must start the engine within 10 seconds of touching the remote to the button.
  • Page 4 2015. If any of the interior is dirty, clean it with mild soap or an Acura cleaning product such as Leather & Vinyl Cleaner (P/N 08700-9214A) or Carpet Spot Remover (P/N 08700-9215A). Clean real wood surfaces (Advance models only) with a mild detergent and a soft, damp cloth.
  • Page 5 To access the battery, you must first remove the front bulkhead cover. To do that, follow these steps: 1. Starting on the passenger side, lift up the far edge of the cover. You will hear a pop as the striker in the cover releases from the latch in the body.
  • Page 6 To install the front bulkhead cover, place it into position, then press down firmly at each striker location until you hear a click. Be sure the bulkhead center section outer corners are tucked under the grille seal. Vehicle Exterior (Vehicle Raised to Full Height) Install the Body Plugs Install the body plugs on each side of the vehicle as shown.
  • Page 7 Vehicle Exterior (Vehicle Lowered to Half-Height) Install the Front License Plate Holder If state regulations require the use of a front license plate, do this: 1. Find the two dimples near the middle of the front bumper. 2. Center the holes in the front license plate holder over the dimples, then attach the holder with the two long Phillips-head screws.
  • Page 8 Under-Hood (Engine Idling) Do the PCM Idle Learn Procedure To ensure a steady engine idle, do the PCM idle learn procedure as follows after installing the No. 16 BACKUP (10 A) fuse: 1. Make sure all electrical items (A/C, audio unit, rear window defogger, lights, etc.) are turned off. 2.
  • Page 9 Set the Clock (Models Without Navigation) To set the clock, follow these steps: 1. Turn the ignition to ON. 2. Press the SETTINGS button. 3. Turn the interface dial to select Systems Settings, then press the ENTER button. 4. Turn the interface dial to select Clock Adjustment, then press the ENTER button. 5.
  • Page 10 ® Check/Refresh the SiriusXM Radio Dealer Demo Service (Except in Alaska and Hawaii) ® The audio system comes from the factory activated with the SiriusXM Radio dealer demo service. Once you install the ® No. 15 RADIO (20 A) and No. 16 BACKUP (10 A) fuses, the system should receive the full range of available SiriusXM channels.
  • Page 11 ® ® Check Bluetooth HandsFreeLink (HFL) To ensure HFL works and is ready to use, start the engine, then press and hold the Hang-up/Back button on the steering wheel for 10 seconds. You should hear “The TCU is OK.” If you do not hear this message, see the service information for troubleshooting information.
  • Page 12 Reset the AcuraLink Control Unit When the No. 16 BACKUP (10 A) fuse is removed during vehicle shipping, the AcuraLink control unit sets DTCs. You need to clear them during the TQI with this procedure: NOTE: After installing the No. 16 fuse, wait at least 30 seconds before doing this procedure. 1.
  • Page 13 NEW MODEL SERVICE INFORMATION Heated Windshield (Advance models) This vehicle comes with a heated windshield that warms the wiper zone. The heater may automatically activate when the outside temperature is below about 39°F and go off above about 42°F. You can also turn on the heater manually using the switch on the left side of the instrument panel.
