Ethan Home 315B WINGBACK KING Assembly Instruction

315B WINGBACK FULL & QUEEN & KING SIZE BED - HEADBOARD

Headboard

1 pc

Bolt

1/4 x 50mm

10 pcs

ASSEMBLY INSTRUCTION

Left Wooden

Right Wooden

Frame

1 pc

Flat Washer

Lock Washer

10 pcs

Left Side Panel

1 pc

Allen Wrench

1 pc

This page lists all the contents included in the

box. Please take the time to identify the

hardware as well as the individual components

to this product. As you unpack and prepare for

assembly, place the contents on a carpeted or

padded area to protect them from damage.

Right Side Panel

1 pc

Back Cover

1 pc

Table of Contents

Need help?

Do you have a question about the 315B WINGBACK KING and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION 315B WINGBACK FULL & QUEEN & KING SIZE BED - HEADBOARD Headboard Left Wooden Right Wooden Left Side Panel Right Side Panel Frame Frame 1 pc 1 pc 1 pc 1 pc 1 pc Bolt Flat Washer Allen Wrench Back Cover Lock Washer 1/4 x 50mm...
Page 2 315B WINGBACK FULL & QUEEN & KING SIZE BED - HEADBOARD Attached left & right Wooden Frame (B)(C) to the Headboard (A) use Bolt (F), Lock Washer (H) and Flat Washer (G). Turn the Allen Wrench (I) in Bolt (F). Attached left &...
Page 3 ASSEMBLY INSTRUCTION 315B WINGBACK KING SIZE BED Wooden Leg Support Leg Footboard Side Rails Wooden Slat 1 pc 2 pcs 39 pcs 2 pcs 8 pcs Iron Pipe Flat Washer Lock Washer Single-Sided Double-Sided Cover Cover 2 pcs 26 pcs...
Page 4 315B WINGBACK KING SIZE BED Attach Wood Leg (D ) to the Footboard (A ). Use Bolt (M ), Lock Washer (J ) and Flat Washer (I ) on both holes. Turn the Allen Wrench (N ) in bolt (M ).
