- Page 1 Assembly Instruc for: SONICMODELL Mini Skyhunter V2 Page | 1...
- Page 2 Thank you for purchasing the SONICMODELL Mini Skyhunter V2! It is important to read the manual in its en ety before your maiden flight. This model is intended , but it can be lots of fun for line of sight as well .
- Page 3 Package Contents: ( KIT version Shown) Fuselage Hardware Package o Elevator Servo Extension FRP Wing reinforcements (1) o Wing Bolts (2 long, 2 short) o Tail screws and nuts (8 each) o Hook and Loop Tape Main Wings Main Spar Tail Booms and Tail Anchors Elevator Rudders...
- Page 4 Assembly 1. Locate Servo Extension and feed it through the le tail boom. Note correct Male/Female orienta on. 2. Connect elevator servo wires. You may wish to secure the connec on with tape or servo clip for added security. Page | 4...
- Page 5 3. Locate 4x small screws and nuts from hardware bag and secure horizontal stabilizer to tail boom anchors. a. Use blue thread lock to help secure the nuts. Be careful to not get any thread locker onto the plas c bracket as it can cause it to weaken. 4.
- Page 6 5. Locate main wings and spar as shown. Insert spar into wing halves and push wings together. 6. Carefully feed elevator cable into the boom housing on the main wing. You will see a small space for the servo connector to pass through. a.
- Page 7 7. Carefully pull the connector through the opening with a small pair of pliersss. In order to reinforce the main wing, we suggest you to install the FRP wing reinforcements as below: 1- Cut the foam according to the reinforcements sheet 2- Locate the reinforcements sheet and glue into place 3- Put the original foam back and glue into place Attention: By doing this, the main wing will be reinforced, but the main wing cannot be...
- Page 8 9. Locate the M3x10 screws and M3 nuts and install them into the main wing boom anchors, but do not en them fully yet. Page | 8...
- Page 9 10. Depending on where you plan to mount your RC receiver, you may wish to install it at this me if you need access to where the wings will be covering. 11. Locate main wing bolts and screw into place. No ce that the short bolts go towards the tail of the airframe.
- Page 10 12. You can now ghten all 4 tail boom clamps. a. Important! Make sure you have proper alignment by measuring the boom lengths and looking at the main wing/tail from different angles. b. Important! If the surfaces are skewed in rela onship to the main wing, it can nega vely affect flight ch aracteris cs.
- Page 11 flight. b. Set the elevator throw to 60% - The Mini Skyhunter V2 does not need much elevator travel. Too much travel and it can roll out of a hard loop.
- Page 12 Center of Gravity: Finished the Mini Skyunter V2 : Enjoy your Mini Sky hunter V2! Please fly responsibly. Page | 12...
