Nova 6060-R How To Assemble

HOW TO
ASSEMBLE YOUR
OverdoorTraction Set
Item # 6060-R
Capacity of weight bag not to exceed 20 lb
Pulley Hangar
Spreader Bar
1

Remove all parts from box:

1 pulley hanger, 1 spreader bar, 1 door bracket, 2 pulley mechanisms, 1 S-hook,
1 head halter, 1 rope, and 1 weight bag
NOTE: It is much easier and safer to assemble this device with help from a second
person.
2
On one of the bent ends of the "PULLEY HANGER", it will have a
locking notch on the side. With the "PULLEY HANGER", turned
upwards, slide that end into the triangle opening of the door
bracket.
3
Once the locking notch slides completely through the "DOOR
BRACKET", turn the "PULLEY HANGER" downwards and slide
on both "PULLEY MECHANISMS.
4
Squeeze the "PULLEY HANGER" and insert the bent end
into the hole at the bottom of the "DOOR BRACKET".
5
Once assembled, install the "DOOR BRACKET" over the top
of an interior door. Ensure the "DOOR BRACKET" is centered
on the door and the top of the bracket is pushed all the way
down. Close the door after secured.
NOTE: Make sure that no one opens the door while you are
using the traction device. If possible, lock the door so that no
one can open it while you are attached to the traction device.
Pulley
Door Bracket
Mechanisms
Head Halter
S-hook
No tools required
All parts included
Easy to follow
step by step
instructions
Weight Bag
Rope
