ATCA-9405
Quick Start Guide
P/N:6806800M81C (May 2014)
1
What's in the box?
Make sure you receive all items of
your shipment:
• ATCA-9405 blade
• Printed Safety Notes
• Any optional items ordered
When installing or servicing the
module or accessories, strictly
observe the safety precautions
in the Safety Notes. Otherwise,
personal injury or property dam-
age may occur.
2
Observe ESD-safe
measures
• Use either a properly grounded ESD
wrist strap or make sure that you are
working in an ESD-safe environ-
ment.
• Connect to the ESD connector at the
front or the rear of the system.
3
Prepare the installation
site
• For information on the environmen-
tal and power requirements, see the
ATCA-9405 Installation and Use man-
ual.
• Operating temperatures refer to the
temperature of the air circulating
around the blade and not to the
actual component temperature.
