- Page 1 SharpMedia™ 2U Platform Installation and Use P/N: 6806800T07B June 2016...
- Page 2 © Copyright 2016 Artesyn Embedded Technologies, Inc. All rights reserved. Trademarks Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other names and logos referred to are trade names, trademarks, or registered trademarks of their respective owners.
-
Page 3: Table Of Contents
Installation of SharpMedia 2U Platform ........ - Page 4 Contents Contents Contents SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 5: Sharpmedia™ 2U Platform Installation And Use (6806800T07B)
List of Tables Table 1-1 Standard and Regulatory Compliances ..........12 Table 1-2 Ordering Numbers . - Page 6 List of Tables SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 7: About This Manual
About this Manual Overview of Contents This manual is divided into the following chapters and appendices. Introduction on page 11 gives a brief overview of the product features, standard safety compliances and ordering information. Hardware Preparation and Installation on page 15 includes a procedure for unpacking the ... - Page 8 About this Manual About this Manual Conventions The following table describes the conventions used throughout this manual. Notation Description 0x00000000 Typical notation for hexadecimal numbers (digits are 0 through F), for example used for addresses and offsets 0b0000 Same for binary numbers (digits are 0 and 1) bold Used to emphasize a word Used for on-screen output and code related elements...
- Page 9 About this Manual Notation Description Indicates a hazardous situation which, if not avoided, could result in death or serious injury Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury Indicates a property damage message No danger encountered.
- Page 10 About this Manual About this Manual SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 11: Introduction
Chapter 1 Introduction The SharpMedia™ Platform is an integrated solution that consists of a Carrier grade 2U server and SharpMedia™ PCIE-8120 acceleration cards. The SharpMedia platform server is installed with CentOS 7.x 64-bit Operating System. SharpMedia™PCIE-8120 acceleration cards are PCI Express based and are designed using the Octasic OCT2224M multi-core Digital Signal Processors (DSPs) along with Vocallo Media Gateway firmware (MGW). -
Page 12: Hardware Components
SharpMedia drivers and utilities Octasic DSP support packages Standard Compliances The SharpMedia 2U Platform meets the following standards, when installed in an appropriate system environment. Table 1-1 Standard and Regulatory Compliances Standard Description EN 55024 European standard for Immunity... -
Page 13: Ordering/Support Information
Introduction Table 1-1 Standard and Regulatory Compliances (continued) Standard Description ETSI EN 300 386 Class A Electromagnetic compatibility and Radio spectrum Matters (ERM); Telecommunication network equipment; Electro- Magnetic Compatibility (EMC) requirements, Class A. Ordering/Support Information The following table lists the product variants and accessories that were available as of the time of writing this manual. - Page 14 Introduction SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 15: Hardware Preparation And Installation
Chapter 2 Hardware Preparation and Installation This chapter provides a brief description about how to unpack and inspect SharpMedia 2U Platform. It also provides environmental, thermal, and power requirements information. Unpacking and Inspecting the Server Platform Damage of Circuits Electrostatic discharge and incorrect installation and removal of the platform can damage SharpMedia PCIE-8120 accelerator cards installed in it. -
Page 16: Environmental, Thermal, And Power Requirements
Hardware Preparation and Installation 3. Remove the desiccant bag shipped with the platform and dispose it according to your country’s legislation. The platform is thoroughly inspected before shipment. If any damage has occurred during transportation, contact our Contact Center immediately. Environmental, Thermal, and Power Requirements Operating temperatures refer to the temperature of the air circulating around the server... -
Page 17: Installation Of Sharpmedia 2U Platform
Hardware Preparation and Installation Installation of SharpMedia 2U Platform For more information on how to install or setup a SharpMedia 2U Platform, refer to Dell PowerEdge R730 Documentation. For more information on how to install or remove a PCIe card into or from a SharpMedia 2U Platform, refer to Dell PowerEdge R730 Owner's Manual. - Page 18 Hardware Preparation and Installation SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 19: Software Initialization
Chapter 3 Software Initialization This chapter explains the various modes of accessing a SharpMedia 2U server. The SharpMedia 2U server comes with pre-configured settings. You can access the SharpMedia 2U either through Ethernet mode or through Serial Console mode. Ethernet - 1G on-board server management port (eno1) labeled as 1 on the server, which is pre-configured with Static IP address, 192.168.0.100. - Page 20 Software Initialization SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 21: Advanced Settings
Chapter 4 Advanced Settings To know more information about SharpMedia 2U Platform server configuration, refer to Dell PowerEdge R730 Documentation. For more information about SharpMedia PCIE-8120 card, refer to Artesyn’s SharpMedia PCIE- 8120 Installation and Use guide. SharpMedia™ 2U Platform Installation and Use (6806800T07B) - Page 22 Advanced Settings SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 23: Related Documentation
Appendix A Related Documentation Artesyn Embedded Technologies - Embedded Computing Documentation The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation. - Page 24 Related Documentation SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 25: Safety Notes
Safety Notes This section provides warnings that precede potentially dangerous procedures throughout this manual. Instructions contained in the warnings must be followed during all phases of operation, service, and repair of this equipment. You should also employ all other safety precautions necessary for the operation of the equipment in your operating environment. - Page 26 Safety Notes Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications not expressly approved by Artesyn Embedded Technologies Embedded Communications Computing could void the user's authority to operate the equipment.
- Page 27 Safety Notes Installation Damage of Circuits Electrostatic discharge and incorrect installation and removal of the product can damage circuits or shorten their life. Before touching the product or electronic components, make sure that your are working in an ESD-safe environment. Product Damage Incorrect installation of the product can cause damage of the product.
- Page 28 Safety Notes SharpMedia™ 2U Platform Installation and Use (6806800T07B)
-
Page 29: Sicherheitshinweise
Sicherheitshinweise Dieses Kapitel enthält Hinweise, die potentiell gefährlichen Prozeduren innerhalb dieses Handbuchs vorrangestellt sind. Beachten Sie unbedingt in allen Phasen des Betriebs, der Wartung und der Reparatur des Systems die Anweisungen, die diesen Hinweisen enthalten sind. Sie sollten außerdem alle anderen Vorsichtsmaßnahmen treffen, die für den Betrieb des Produktes innerhalb Ihrer Betriebsumgebung notwendig sind. - Page 30 Sicherheitshinweise Das Produkt wurde in einem Artesyn Embedded Technologies Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten gewährleisten.
- Page 31 Sicherheitshinweise Überhitzung und Beschädigung des Produktes Betreiben Sie das Produkt ohne Zwangsbelüftung, kann das Produkt überhitzt und schließlich beschädigt werden. Bevor Sie das Produkt betreiben, müssen Sie sicher stellen, dass das Gerät über eine Zwangskühlung verfügt. Fehlerhafter Datenbestand Wenn sie die Spannungsversorgung des Produkts abschalten, während Programmdaten im Flashspeicher aktualisiert, werden, können diese Daten nicht korrekt gespeichert werden.
- Page 32 Sicherheitshinweise Installation Beschädigung von Schaltkreisen Elektrostatische Entladung und unsachgemäßer Ein- und Ausbau des Produktes kannSchaltkreise beschädigen oder ihre Lebensdauer verkürzen. Bevor Sie das Produkt oder elektronische Komponenten berühren, vergewissern Sie sich, daßSie in einem ESD- geschützten Bereich arbeiten. Beschädigung des Produktes Fehlerhafte Installation des Produktes kann zu einer Beschädigung des Produktes führen.
- Page 34 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2016 Artesyn Embedded Technologies, Inc.
