This product is a USB Type-C screen transmitter wireless dongle. It supports sharing contents from screen sources (e.g., laptop) to a display device wirelessly through Hall Technologies Specified AV equipment. It supports transmitting up to 1080P video signal with audio and supports touch back-post feature when sink display is a touch screen.
Panel Description Name Description Connect to Hall Technologies Specified AV equipment for USB Type-C pairing, or source device with USB Type-C port (Support DP) for Port projecting screen. Press the button to freeze/unfreeze the projected screen (the frame on source device is not affected).
Page 4
Note: For more detailed operations about the receiver, please refer to its user manual. a. Connect the USB Dongle to Hall Technologies Specified AV equipment for pairing up. b. Then “Starting pairing…” will appear on the display screen connected to the receiver. The Dongle’s LED will be blinking.
Page 5
3. Now short press the Projection button, you can project your laptop’s screen to the display screen immediately. The LED will light dimly white during the projection. Display Display Dongle HT-Voyager Dongle Dongle Laptop Laptop HT-ATLAS Speakerphone Enter full screen mode: When there are multiple screens (including screen projected through the Dongle) shown on the sink display, hold projection button for about 2 seconds, you can have your laptop’s screen displayed in full screen.
Input Voltage 5V (Power over USB) Power Consumption (Max) 2.2W Product size (φ x h x l) 68.98mm x 16.4mm x 165.19mm/2.72” x 0.65” x 6.50” Product Weight 60g/0.13lb (net weight) Hall Technologies September 1, 2022 Page 6 of 7...
