- Page 1 ® DYNA-FOG ™ TYPHOON MANUAL MODEL 2984 SERIES 2 ULV APPLICATOR MANUFACTURED BY: CURTIS DYNA-FOG, Ltd. 17335 U.S. Highway 31 North WESTFIELD, INDIANA, U.S.A. www.dynafog.com INNOVATORS OF SPRAYING AND FOGGING DEVICES...
- Page 2 OPERATION AND MAINTENANCE MANUAL DYNA-FOG TYPHOON 1 ULV AEROSOL APPLICATOR (UNITED STATES AND FOREIGN PATENTS PENDING) MANUFACTURED BY: CURTIS DYNA-FOG Ltd. 17335 U.S. HWY. 31 NORTH P.O. BOX 297 WESTFIELD, IN 46074-0297 USA...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION…………………………………………………………………………………………..1.0 SPECIFICATIONS……………………………………………………………………………………….. 2.0 FOREWORD……………………………………………………………………………………………… 2.1 DESCRIPTION………………………………………………………………………………………….. 2.2 WORKING PRINCIPLES………………………………………………………………………………. 2.3 FLUID PUMPING SYSTEMS AVAILABLE…………………………………………………………… MAJOR COMPONENTS DIAGRAM…………………………………………………………………………. 3.0 ASSEMBLY INSTRUCTIONS…………………………………………………………………………… 3.1 CHARGING THE BATTERY…………………………………………………………………………… 3.2 MACHINE INSTALLATION…………………………………………………………………………….. 4.0 SAFETY PRECAUTIONS………………………………………………………………………………… 5.0 MACHINE OPERATION………………………………………………………………………………….. 5.1 PRE-SPRAY CHECKLIST………………………………………………………………………………. 5.2 BLOWER PREPARATION………………………………………………………………………………. -
Page 4: Introduction
Properly maintained, the TYPHOON 1 will provide years of trouble free service. We trust you will agree, the Typhoon 1 will be a great asset to any spraying program. Thank you for choosing DYNA-FOG. -
Page 5: Specifications
MACHINE SPECIFICATIONS TYPHOON 1, MODEL 2984 TYPE: ULV, NON-THERMAL AEROSOL APPLICATOR ENGINE: 9.5 HP KOHLER, 4-CYCLE, OVERHEAD VALVE, GASOLINE POWERED, ELECTRIC START. OIL CAPACITY: 1.16 QTS. (1.1 LTRS.) BLOWER: HIGH VOLUME, POSITIVE DISPLACEMENT, ROTARY TYPE, OPERATING DATA: 8.5 PSI @ 2750 RPM MAXIMUM OUTPUT: 12 PSI (.82 BAR) -
Page 6: Foreword
FOREWORD The application of insecticides is the predominate method by which man attempts to control the size of insect populations. Due to environmental and economical reasons, it is desirable to treat a given area with the least amount of insecticide that can be made to be effective. -
Page 7: Working Principles
The system must be flushed after each use. FLUID PUMPING SYSTEMS There are three types of pumping systems available for the TYPHOON 1 ULV: 1) (MODEL 2984-1) FMI (SET-FLOW) Ceramic Piston-Pump: This highly accurate pumping system utilizes a 12 volt DC motor to drive a ceramic, rotary piston-pump. -
Page 8: Major Components Diagram
MAJOR COMPONENTS TYPHOON 1 FORMULATION PUMP ENCLOSURE TANK BATTERY BOX FRAME 3-WAY VALVE BLOWER INTAKE FILTER FLUSH TANK BLOWER PRESSURE GAUGE ENGINE COUPLING GUARD COUPLING 2-WAY SOLENOID VALVE ® CURTIS DYNA-FOG Ltd. BOOM SPRAY NOZZLE... -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1) Uncrate the unit and remove all packing materials. NOTE: It is a good idea to retain the original machine-shipping carton for storage. 2) Place the remote control unit where it will not be damaged while the machine is being installed. -
Page 10: Machine Installation
CHARGING THE BATTERY (CONT'D) D. Charge 12 volt battery at 30-40 amps until the acid temperature is above 80 F (26 C), and the hydrometer reading is 1.250 or higher. Acid temperature must never exceed 125 F while charging. NOTE: Both temperature and hydrometer readings must be met. - Page 11 MACHINE INSTALLATION (CONT'D) 3. Once the cable has been routed to the cab, reseal all drilled openings to prevent moisture and/or exhaust gases from entering the cab. MANUAL REMOTE CHOKE: 4. Remove the cover from around the fuel shut-off, and choke levers. Doing this will allow you access the choke cable mounting hole, on the choke lever.
- Page 12 MACHINE INSTALLATION (CONT'D) 5. Using the (3) hold-down brackets used for mounting the machine to the shipping skid, securely mount the machine to the bed of the vehicle (see diagram below). Depending on the type of surface the machine is being mounted onto, it may be necessary to use additional mounting hardware to secure the machine.
-
Page 13: Safety Precautions
SAFETY PRECAUTIONS WARNING READ AND UNDERSTAND THESE SAFETY PRECAUTIONS BEFORE OPERATING MACHINE 1. ENGINE AND FUEL: This machine uses gasoline as the fuel for the internal combustion engine and all precautions commonly applying to this volatile fuel should be observed. Exercise extreme caution to avoid spilling of gasoline. If spillage occurs, wipe it off and allow evaporation time before starting the engine. - Page 14 SAFETY PRECAUTIONS (CON’T) 4. WIND: Spraying during windy conditions is not usually practical because the formulation will drift out of the intended area. However, under NO circumstances should spraying into the wind be attempted. This may cause hazardous accumulations on the machine or carrying vehicle.
-
Page 15: Machine Operation
MACHINE OPERATION CAUTION Read this complete operation section and the section on safety precautions before starting the machine for the first time. For first time operation, the sections on MACHINE INSTALLATION and MACHNE OPERATION must be performed before proceeding with this section. When operating this machine for the first time, move to an uncongested and well-vented work area away from flammable materials. -
Page 16: Pre-Spray Checklist
PRE-SPRAY CHECK LIST 1. Verity that the formulation pump has been calibrated and is dispensing formulation in accordance with the manufacturers label requirements. 2. Verify that the adjustable nozzle boom is in the correct position as required for the spraying operation to be accomplished, and that the ring clamp which allows this positioning is tight. -
Page 17: Blower Preparation
BLOWER PREPARATION The blower on your machine has already been filled with a non-detergent, SAE 40 grade oil. It should not be necessary for you to use a different grade of oil unless the machine will be operated in climates with a temperature above 90 F (32 C). In applications where the machine will be operated for extended periods above 90 F (32 C), use SAE-50 grade oil. -
Page 18: Starting The Engine
STARTING THE ENGINE 1. OPEN THE FUEL VALVE: Turn fuel valve lever right 1/4 turn. 2. CHOKE ENGINE: Move engine or remote choke control to position lever in "choke" position. NOTE: This should fully close choke on carburetor. If it does not, remote control must be readjusted to enable full travel of the choke lever. - Page 19 MEASURING LIQUID VISCOSITY (CONT'D) 3. The viscosity of the liquid. Various liquids have different viscosities. Viscosity is defined as a fluids resistance to flow commonly measured in units of a centipoise (CP). Generally, the thicker the liquid, the greater the viscosity and the higher the CP number. Examples of some liquid viscosities are: LIQUID VISCOSITY (CP)
- Page 20 MEASURING LIQUID VISCOSITY (CONT'D) Once the flowability of the liquid has been measured, tables 1 and 2 can be used as an approximate guide for setting the pump flow rate and nozzle boom pressure for your spray application. NOTE: Periodically calibrate the flowability meter using plain water. Water should flow through the orifice such that the time between the top line and the bottom line is 32 + 2 seconds.
-
Page 21: Droplet Size Vs. Flow Rate And Boom Pressure
DROPLET SIZE (VOLUME-MEDIAN-DIAMETER) FLOW RATE AND BOOM PRESSURE Once the flowability of the formulation to be sprayed has been determined and the formulation pump has been calibrated to produce the flow rate specified on the formulation label, select one of the two tables below that is closest to the flowability of the formulation to be sprayed (35 seconds or 85 seconds). -
Page 22: Preventative Maintenance
PREVENTATIVE MAINTENANCE NOTE: A successful maintenance program begins after the first use of the machine and not after the machine has ceased to function. PREVENTATIVE MAINTENANCE: 1. Occasionally inspect mounting hardware to ensure that fasteners are tight. Loose hardware can cause excessive vibration leading to major failure of components. 2. -
Page 23: Blower Intake Filter
FILTER - SILENCER (Rotary Blower) A) General : The air blower filter - silencer is mounted on the air blower. Dirt and other foreign particles are filtered from the incoming air by means of the reusable stainless element. The design is such that it partially silences the air also. -
Page 24: Formulation Filter Maintenance
FORMULATION FILTER The system is equipped with an in line low profile filter located at the formulation tank standpipe. This filter is to prevent any foreign matter from entering the Pump, solenoid valve and the nozzle system. Located inside the filter housing is a fine mesh stainless steel screen and a Aflas gasket seal. - Page 25 PREVENTATIVE MAINTENANCE SCHEDULE TABLE 3 FREQUENCY 8 HRS OR 25 HRS OR 50 HRS OR 100 HRS OR 100-300 HRS MAINTENANCE OPERATION DAILY NEW SEASON NEW SEASON NEW SEASON ENGINE CHECK OIL LEVEL CHANGE OIL SERVICE PRE-AIR FILTER SERVICE AIR FILTER DEBRIS GUARD (OPTIONAL) CLEAN COOLING SYSTEM (FINS) INSPECT SPARK ARRESTER...
-
Page 26: Flushing The System
FLUSHING THE SYSTEM The system must be flushed after each use to protect the equipment from the corrosive material in the formulations. CAUTION Never handle any parts on the machine that come in contact with formulation until the unit has been thoroughly flushed with isopropyl alcohol or other recommended flushing agent. -
Page 27: Nozzle
ULV NOZZLE ASSEMBLY The design of the ULV Nozzle is such that it should require little maintenance if the machine is properly flushed after each use. However, if it becomes necessary to clean the entire Nozzle Assembly, refer to steps 1-7. To inspect the inside of the Nozzle it is not necessary to remove the entire Nozzle Assembly from the machine. -
Page 28: Drive Coupling
HI-FLEX COUPLING INSTALLATION INSTRUCTIONS FLANGE AND BUSHING INSTALLATION Make sure the bore and tapered cone surface of the bushing and flanges are free of all foreign substances such a paint or dirt. Place *QD bushing on the shaft over the key with flange end first. The end of the bushing should be flush with the end of the shaft for best results. - Page 29 CAUTION : Never allow the flange assembly to be drawn in contact with the flange of the *QD Bushing. There should be a gap from “1/8" TO 1/4" between them. If the gap is closed, the shaft is seriously undersize. Bolts of *QD Bushing: 1/4-20 x 1-1/4 , grade 5.
- Page 30 INSTALLATION OF FLEXIBLE ELEMENT You may loosen the flange assembly screws as much as possible without disassembly of cover or you may remove the screws completely thus disassembling the cover. In either case wrap the flexible element around the flange assembling. Make sure the beads of the element are fully worked down upon the seats of covers as shown in the detail on the right...
-
Page 31: Storage And Shipment
STORAGE & SHIPMENT PREPARING THE BLOWER FOR STORAGE In preparing the blower for storage, the inner workings of the blower must be coated with a rust inhibiting oil. This is done by removing the air filter/silencer by turning it counterclockwise (CCW). After the filter/silencer is removed, access to the inner workings is possible. - Page 32 STORAGE AND SHIPMENT (CONT'D) PREPARING THE BATTERY FOR STORAGE Disconnect positive (+) and negative (-) battery cables and wrap cable ends with electrical tape. Remove battery and store in a cool dry area. PREPARING THE FRAME ASSEMBLY FOR STORAGE The frame should be wiped down with Isopropyl Alcohol and dried. If original shipping carton is not available the unit should be covered with a tarpaulin or plastic sheet.
-
Page 33: Systems Flow Diagram
VENTED CAP VENTED CAP FLUSH TANK 3-WAY VALVE (MANUAL OR NOZZLE SOLENOID) FORMULATION FILTER TANK INTERCHANGEABLE RESTRICTING ORIFICE (DIAPHRAM PUMP ONLY) DROPLETS 2-WAY SOLENOID VALVE BLOWER PRESSURE GAGE TYPHOON 1 FLUIDS SYSTEM DIAGRAM (TO PRESSURE SWITCH) -
Page 34: Electrical Schematic (Excluding Pumping System)
WIRING DIAGRAMS "SPRAY" SOLENOID (EXCLUDING PUMPING SYSTEM) VALVE BLUE/WHITE GREEN BLACK REMOTE KILL RED/BLACK REMOTE START ENGINE WIRING +12 VDC CHASSIS GROUND MACHINE WIRING DIAGRAM CHARGING VOLTAGE REGULATOR REMOTE KILL BLACK/WHITE RED/WHITE REMOTE START RED/WHITE RED/WHITE STARTER MOTOR STARTER SOLENOID ENGINE WIRING DIAGRAM... -
Page 35: Engine Assembly
ENGINE ASSEMBLY P/N 64730-2 ITEM QTY DESCRIPTION 63458-1 FLANGE AY, OUTSIDE MNT. 139009 SCREW, SET, ¼-28 x ¼ 63460-7 1˝ SH BUSHING 62549 KEY ¼ x 1-3/4 49150 ENGINE, KOHLER 9.5 HP 64016 HOURMETER/TACHOMETER 49078 HARNESS, ADAPTER (B&S) 85685 CONNECTOR 3M... -
Page 36: Tachometer/Hourmeter
TACHOMETER / HOURMETER THE NEW MODEL OF THE TACHOMETER/HOURMETER ALLOW THE POSSIBILITY TO USE THE MAINTENANCE METER TO ALERT MAINTENANCE PERSONNEL THAT A TIME INTERVAL HAS EXPIRED AND SERVICE SHOULD BE PERFORMED ON THE ENGINE. INTRODUCTION The ENGINE MONITOR is a self powered LCD Hourmeter/Tachometer and Maintenance Meter. -
Page 41: Nozzle Assembly
ULV NOZZLE ASSEMBLY P/N 64630 ITEM # DESCRIPTION 64650 TUBE, NOZZLE SPRAY 64647 BODY, NOZZLE 10100-153 O’RING, 3.693 OD 64649 DISC, NOZZLE, MACHINED 64643 SCREW, #10-24 x 3/8, SST 64642 SCREW, #6-32 x 3/8, SST 64651 FIN/NOZZLE CONE AY 422987 NUT, JAM 5/46-24... -
Page 42: Flexible Coupling
1.12 (REF.) ENGINE SHAFT BLOWER SHAFT FLEXIBLE COUPLING ASSEMBLY ITEM DESCRIPTION 63460-3 BUSHING, 1˝ BORE 63458-1 FLANGE AY, OUTSIDE MOUNT 63458-2 INSERT, COUPLING 63458-4 FLANGE AY, INSIDE MOUNT 63460-2 BUSHING, 7/8˝ BORE 63438 BOLT, HEX ¼-20 x 1 ½... -
Page 43: 3-Way Valve Assembly
TO FLUSH TANK TO FORMULATION TANK TO INPUT PORT OF PUMP 3-Way Valve/Bracket AY. P/N 64639-1 (Diaphragm & FMI Pumps) ITEM DESCRIPTION 64619 BRACKET, VALVE MNTG 63686 LABEL, FLUSH 63685 LABEL, FORMULATION ASC-35 ELBOW, 1/4FP-1/4MP 62558-5 FILTER, LOW PROFILE 62554-4 ELBOW, 1/4FP-3/8T 62641-2 ELBOW, 1/4MP-1/4T... -
Page 44: Formulation Tank Assembly
DETAIL P/N 64004 FORMULATION TANK ASSEMBLY ITEM DESCRIPTION 64002-1 TANK, 15 GAL 64077 CAP, LOCKABLE 63094 LABEL, FORMULATION 62574 FORMULATION STANDPIPE ASS’Y 62573-2 CONNECTOR, MALE, MOD. 62545 FORMULATION STANDPIPE 62550-3 CONNECTOR, MALE, MOD. 62553-3 CONNECTOR, UNION 3/8 T 64772 BUSHING, NL, 3/4 P – 3/8 P... -
Page 45: Flush Tank Assembly
FLUSH TANK ASSEMBLY (1 GALLON), P/N: 63337-1 ITEM QUANTITY PART NUMBER ITEM DESCRIPTION 63302-6 TANK, 1 GAL. (MACHINED) 62592 LABEL, FLUSH 62553-1 CONNECTOR, UNION, 1/4 T 62550-1 NUT, .25, STEEL GRIP 114628 SLEEVE, 1/4 T 145463 NUT, 1/4 T 10105 CONNECTOR, STANDPIPE 53131 WASHER, FLAT... -
Page 46: Steel And Plastic Gripper Nuts
SAMPLE CONNECTIONS USING STEEL & PLASTIC GRIPPER NUT... -
Page 50: Conversion Tables
13.0 CONVERSION TABLES TO CONVERT MULTPLY BY MILLIMETERS......INCHES......…. .03937 CENTIMETERS.......INCHES.......… .3937 METERS.......……..FEET..…....3.281 SQUARE METERS..……SQUARE FEET..... 10.764 SQUARE METERS....ACRES....….. .000247 CUBIC METERS.....……CUBIC FEET..…... 35.31 GRAMS......……….OUNCES(FLUID).……..… MILLILITERS....…..OUNCES....…..0338 LITERS......……GALLONS..……....264 KILOGRAMS....……POUNDS....……..2.204... - Page 51 Diversity of pumping systems, Gear, Piston and Diaphragm. Pressurized system available for overseas market. Optional Radar Syncroflow. 40 cc Two cycle portable machines also available. ® 17335 US Highway 31 North CURTIS DYNA-FOG Ltd. Westfield, IN 46074 U.S.A. www.dynafog.com www.dynafog.com Phone: (317) 896-2561...
