- Page 1 INSTALLATION and PAIRING INSTRUCTIONS 98GCK-47 Rev.02132018 RV AWNING PRODUCTS 1361 CALLE AVANZADO, SAN CLEMENTE, CA 92673 (800) 382-8442 FAX (949)276-5500 www.girardrv.com...
- Page 2 Shore Power – if connected; Generator Power – if the generator is running; Inverter Power – batteries must be charged for inverter operation. Girard Systems awnings are supplied with an electric motor appropriate to the product.
-
Page 3: Table Of Contents
These components must be electronically matched, programmed or paired before use. This is usually done at the Girard Systems factory. Should the need arise for the user to pair a device with the motor controller they must refer to the appropriate manual for the devices applicable to their particular installation. -
Page 4: 98Gc274B Product Description
98GC274B PRODUCT DESCRIPTION AC Motor Controller with LED (12V DC) control plus Ignition retract and lockout. STOP Fig.1 • This module is designed to control a single Standard 110v AC Motor up to 8 Amps and can be remotely operated with any paired G-Link handset or wall switch. -
Page 5: Specification
Fig.2 1) 110v AC Power supply from vehicle power distribution board. 2) Output to awning motor control. 3) Initiate retract signal from vehicle ignition or parking brake. 12v DC to LED lighting Specifications Power: 110VAC / 60Hz AC Input: White = Neutral / Black = Live / Green = Earth To the Motor: White = Neutral / Red = Direction 1 / Black = Direction 2 / Green = Earth Ambient T:... - Page 6 Route the Awning’s Motor cable to this location and make the connections to the GC274B in accordance with NEC requirements. Mount the GC274B on the wall using the screws and tape provided.
-
Page 8: Setup And Programming
SETUP AND PROGRAMMING 1. Change motor direction a. Supply power to GC274B b. Simultaneously press the LEFT and RIGHT buttons of the GC274B for at least 6 seconds. The Green LED will illuminate and then blink a few times. When the Green LED extinguishes, the operation is complete. -
Page 9: Cancel A Remote Or All Remote From Gc274B
3. Cancel one Remote from the GC274B a. Supply power to the GC274B b. Press and hold the MIDDLE and RIGHT buttons on the GC274 (Fig 3) for about 3 seconds until the Green LED starts to flash. c. Press STOP (Fig. 1): The Green LED will stop blinking and remain illuminated. d. -
Page 10: Multichannel Handset Remote
98GC2762B MULTI CHANNEL REMOTE HANDSET PRODUCT DESCRIPTION The 98GC2762 remote handset is a Multi-channel RF transmitter, powered by a single 3v Lithium battery (CR2450) designed to control up to 15 awnings and operate the LED lighting strips by means of a multi-functional circular control pad. As shown in Fig.1 below. -
Page 11: Programming The Gc274B To A Remote Handset 98Gc2762B
Fig.4 Programming a Remote handset to 98GC274B a. Supply power to the GC274B b. Press and hold the MIDDLE and RIGHT buttons on the GC274 (Fig 3) for about 3 seconds until the Green LED starts to flash. c. Press STOP (Fig. 1): The Green LED will stop blinking and remain illuminated. - Page 12 To find the battery turn the remote handset over and slide the cover down; • The Battery compartment, (into which a single CR2450 3v Lithium battery should be inserted as shown, Fig.5) • The P2 button (used when pairing the device to some other G-Link Modules) Fig.5...
- Page 13 Magnetic Holder.- This new G link transmitter was designed with a magnetic plate holder to keep it in place and make it more user friendly. See Fig 6 below. Fig.6...
- Page 14 To install the plate holder to the coach it is necessary to remove the front cover to have access to the mounting holes, see Fig.7 below. Fig.7...
-
Page 15: Multichannel Wall Switch 98Gc2763B
98GC2763B MULTI CHANNEL WALL SWITCH PRODUCT DESCRIPTION The 98GC2763B is a Multichannel RF transmitter, powered by two 3v Lithium batteries (CR2430) designed to control up to 20 awnings. See figure 8 for description of each pad. -
Page 16: Programming The Gc274B To A Wall Switch 98Gc2763B
Fig.8 Programming a Wall Switch to 98GC274B a. Supply power to the GC274B b. Press and hold the MIDDLE and RIGHT buttons on the GC274 (Fig 3) for about 3 seconds until the Green LED starts to flash. c. Press STOP (Fig. 1): The Green LED will stop blinking and remain illuminated. - Page 17 To find the batteries turn the wall switch over and using a small flate screw driver pull the cover off, the cover has the word “open” on the right bottom corner, see Fig.9 below. • The Battery compartment, (into which three CR2430 3v Lithium battery should be inserted as shown) Fig.9 Magnetic Holder.- This new G link transmitter was designed with a magnetic plate...
-
Page 18: Programming To A Motion Sensor
98GC779G REMOTE MOTION SENSOR Programming the GC274B to a Motion Sensor (98GC779G) This procedure will require opening the motion sensor module by following the directions below; Remove the 2 small cross head screws which secure the motion sensor to the mounting bracket. - Page 19 Fig.12 c. Remove the 4 cross head screws holding the module together. Remove the back plate and silicone insert. See Fig.13. Base plate Magnet Silicone Insert Fig.13...
- Page 20 d. Turn the base plate over (Magnet down). Then place the motion sensor on top of it so that the magnet is aligned with the reed switch. See fig.14. If this is not done the default program cannot be changed. Reed Switch Program Button Sensitivity Dial...
- Page 21 Once programming is complete, reassemble the motion sensor module and mount on the awning lead rail. For queries or assistance with programming any of your G-Link devices please call Girard Systems TOLL FREE on 800–382–8442 between 7:30am and 3:30pm P.S.T.
