Installation Instructions
ITEMS YOU WILL NEED TO INSTALL THE BOX
•
2 ropes or straps to carry and lift box
•
Shovels
•
Tape measure
•
Spirit level or levelling device
•
Rubber mallet
Electrical Bonding AS/
NZS 3000:2018
(Wiring Rules):
If unit is installed within
arm's reach (1.25m) of
the pool edge, engage
a licenced electrician
to equipotential bond
the unit. Check state
legislation before
commencing works.
Below Ground Box
•
17mm socket or spanner
•
2 concrete slabs 450mm x 450mm or
300mm x 600mm
•
Blue metal or stone aggregate equivalent
(approx. 2 bags per 1sqm).
256
Below Ground Box Small Model
pool covers & rollers
220
Advertisement
Related Manuals for Daisy Below Ground Pool Cover Box
Summary of Contents for Daisy Below Ground Pool Cover Box
- Page 1 pool covers & rollers Installation Instructions ITEMS YOU WILL NEED TO INSTALL THE BOX • 2 ropes or straps to carry and lift box • 17mm socket or spanner • Shovels • 2 concrete slabs 450mm x 450mm or • Tape measure 300mm x 600mm •...
- Page 2 INSTRUCTIONS Prepare dig zone by removing Once both slabs are in place and at correct level, place pavers if being installed into for sufficient drainage, blue metal or aggregate along pre paved area. the trench making sure you do not exceed more than 50mm above the slab height, for boxes with a centre brace or braces leave a small amount out so brace doesn’t touch the blue metal.
- Page 3 C. Alternatively, Daisy’s convenient new invention, the Daisy Drill Drive allows you to wind up your BGB with a standard power drill. Simply use the extension arm and turn on your drill. Your Daisy Pool Cover will quickly and easily wind into the BGB.
- Page 4 Apply smear of marine grade grease to gearbox shafts REGISTER YOUR WARRANTY ONLINE Your Daisy can last for so many years! So it’s a good idea to register your warranty online with Daisy. We’ll keep all your details safe, so you don’t have to worry! Two easy steps: Scan your purchase receipt.
