- Page 1 STAR SBM-050WP USER MANUAL Digital Baby Monitor 5" TFT LCD Display...
- Page 2 About this manual. We have made every effort to ensure that the contents of this manual are correct and as up-to-date as possible. Ho wever, there is no guarantee that new versions of the soft ware will not contain changes that render some parts of this manual obsolete.
-
Page 3: Table Of Contents
Contents Safety notes ................2 Appearance of the device ............3 Camera Transmitter ............3 Portable display ............... 4 Button description ..............5 Description of functions ............7 Camera ................7 Portable display ..............9 Menu ................12 Camera ..............13 Pairing instructions ..........14 Choosing a lullaby ...........15 Feeding Reminder ...........15 Sound settings ............15... -
Page 4: Safety Notes
Safety Notes Please remember that the baby monitor does not rep lace responsible adult supervision. This product should be placed in a location where the child will not come into contact with it, and the distance between the baby monitor and the child should be at le ast 1,5-2 metres to ensure that the child and this pro duct have a suitable safety zone. -
Page 5: Appearance Of The Device
Appearance of the device Camera Transmitter Camera Antenna Microphone Temperature IR sensor sensor IR emitters Power connector LED indicator 10. Mounting bracket Speaker 11. Pairing button. -
Page 6: Portable Display
Portable display Antenna 8. Talkback button 9. Display Power button Camera switching 10. Microphone button 11. Speaker Menu/return button 12. Mounting bracket Navigation buttons 13. Power connector OK button 14. Battery cover Quick music change 15. Reset button button... -
Page 7: Button Description
Button description Power button: — hold down to turn on\off the digital video baby monitor, press once to turn on\off the screen. OK button: confirms the selection in the menu. Menu/Back button: — short press: launch the menu; long press: start PTZ (Pan-Tilt-Zoom) mode. Navigation buttons: —... - Page 8 Quick music switch button: Lets you instantly start or stop lullaby right from your home screen. If lullaby is already playing, short press of this button changes the melody. Reset button: If the baby monitor does not start with the power button, press to force restart the device. Pairing Button: Connects the handheld display and the camera to each other.
-
Page 9: Description Of Functions
Description of functions Camera This unit operates on 5V\1A DC power. When the device is turned on, the blue indicator light will illu minate, indicating that the baby monitor is on and ready for use. Note: please use only the supplied power adapter. Night vision: the baby monitor is equipped with 8 infrared sensors that allow it to see a clear picture even in total dark ness, without disturbing the child. - Page 10 If the picture or sound does not go well, try moving the devi ce to another location for the best signal quality. Adjusting the camera angle: Press the menu button to enter the camera angle setting interface and then use the directa tional keys.
-
Page 11: Portable Display
Portable display The product is powered by the integrated battery or the 5V/1A DC adapter. The built-in battery can be charged auto matically when connected to the DC adapter. Power on/off: Turn on the power to the unit, press and hold the button for 1.5 seconds to turn the power on/off. - Page 12 Portable Display Status Icons: Signal strength icon; Air temperature in the children's bedroom; Lullaby icon; Night Vision icon; Mute icon: indicates that the display is muted; 6. The VOX icon: indicates the voice activation mode is on.
- Page 13 The volume level at which the screen turns on can be adjusted. There three sensitivity modes: «Low», «Medium» and «High». 7. Current time; 8. Feeding reminder icon; 9. Microphone icon; Indicator of an activated camera. Battery charge indicator. Direction indication (PTZ interface): shows the direction of camera rotation.
-
Page 14: Menu
Menu The following options are available in the menu: Press the Menu/Return button to open a sub-menu. Camera settings. Lullaby choice. Feeding reminder. Sound settings. VOX sensitivity settings. -
Page 15: Camera
Other settings. Press «left» and «right» to move between sections, «up» and to select, «OK» to confirm, «Menu/return» button to exit. Camera Select Camera settings and enter the following menu: Removing the camera. Pairing cameras: Once successfully paired, settings will be saved, so there is no need to repeat the procedure the next time you turn it on. -
Page 16: Pairing Instructions
The screen is divided, i.e., camera 1 and occupy half the left and right screen, respectively. Cyclic automatic camera switching. Pairing instructions → → Menu button Camera settings Pairing → Select camera → At this point, the blue light should turn on, indicating that the camera is being searched for. -
Page 17: Choosing A Lullaby
Choosing a lullaby You can select one of the six available songs or play them alternately in a loop. You can also press the «Music button» shortcut to quickly set up this menu. Feeding reminders Select the feeding reminder setting, with 5 clock set tings to choose from: snooze the reminder function, re minder every hour, reminder every 2 hours, reminder ev ery 3 hours, reminder every 4 hours Select one of them... -
Page 18: Vox Sensitivity Settings
VOX sensitivity settings The vehicle battery is not designed to be used for extended pe riods of time with the vehicle being used. Other settings Select other settings, the menu shown in the illustration is dis played: Display frequency setting: up to-1 The power supply is operated at 60 Hz or 50 Hz. -
Page 19: Mounting
Mounting Place the baby monitor at an appropriate height and careful ly adjust the angle of the camera to have the most comforta ble viewing angle to monitor your baby. For convenience, you can also attach the baby monitor to a special bracket. - Page 20 Do not use a rough or stiff cloth that could scratch the out side of the unit. To reduce the risk of electric shock, do not open or repair the unit yourself. Store the device in a dry place. Do not use the baby monitor in an excessively humid environment: use in a humid envi ronment may cause the device to malfunction.
-
Page 21: Disposal Of The Device
Disposal of the Device (environment) At the end of the product life cycle, you should not dispose of this product with normal house- hold waste. Take this product to a collection point for the re- cycling of electrical and electronic equipment. The symbol on the product, user’s guide and/or box indicates this. -
Page 22: Help
Help Display – Try recharging the battery pack. – Reset the Units. Unplug both the Units' electrical power, then plug them back in. – Is the Unit switched on? Press and hold the ON/OFF button on the Parent Unit for 3 seconds to switch it ON. –... - Page 23 – Reset both the Parent Unit and Baby Unit by disconnecting them from the electrical power. Wait about 15 seconds befo- re reconnecting. Allow up to one minute for the Baby Unit the Parent Unit to synchronize. – See Pairing section of this manual, if there is a need to re- register the Units.
- Page 24 Noise interference on your device – To avoid background noise or echoes, ensure that there is enough distance between your device and the Camera Unit. – Use of other 2.4 GHz products, such as Bluetooth™ sys- tems or microwave ovens, may cause interference with this product.
-
Page 25: Warranty
Thank you for purchasing this SOON product. What Does this Warranty Cover? Subject to the exclusions contained below, SOON warrants that product («Product») or certified accessory («Accessory») sold for use with this product that it manufactured to be free from defects in ma- terials and workmanship under normal consumer usage for the period outlined below. - Page 26 Who is covered? This Warranty extends only to the first consumer purchaser, and is not transferable. Warranty Period One (1) year from the date of the first purchase by the first purchaser-customer. Exclusions Normal Wear and Tear. Periodic maintenance, repair and replacement of parts due to normal wear and tear are exc- luded from coverage.
- Page 27 SOON, are excluded from coverage. Unauthorized Service or Modification. Defects or dama- ges resulting from service, testing, adjustment, instal- lation, maintenance, alteration, or modification in any way by someone other than SOON or its authorized service centers, are excluded from coverage.
-
Page 28: Technical Specifications
Technical Specifications Baby Monitor Frequency 2400 MHz–2483.5 MHz IR sensors: 8 units Operating temperature 5° C–40C Power Adapter Input: 100-240V AC, 50/60Hz; Output: 5.0V DC, 1000mA Handheld Display Frequency 2400 MHz—2483.5 MHz 16.7M color 5” LCD TFT screen Power Adapter Input: 100-240V AC, 50/60Hz; Output: 5.0V DC, 1000mA Battery: Li-Pol 1500 mAh Specifications are subject to change without notice. - Page 29 Manufacturer: Dongguan HDKing Smart Technology Co. LTD. Floor 2, Building C, Hechang Road No.8, Shatou Community, Changan Town, Dongguan, Guangdong, China. Fax: +86-0769-81666975. Tel: +86-0769-81666972. Distributor in RF: «Socinteh» 111250, Russia, Moscow, Krasnokazarmennaya str. 10, room 10. Importer: «Socinteh» 111250, Russia, Moscow, Krasnoka- zarmennaya str.
