- Page 1 Vacuum cleaner User manual VS20A95**** Series • Before operating this unit, please read the instructions carefully. • For indoor use only...
-
Page 2: Table Of Contents
Contents Safety information Operation Important safety symbols Installing the Clean Station General Using the Clean Station Vacuum cleaner Charging the battery Maintenance Inserting the battery Clean Station Ejecting the battery Battery Charging the additional battery Using the buttons and display Using the Accessory Cradle Preparation Using the accessories... -
Page 3: Safety Information
Safety information • Before operating the appliance, please read this manual thoroughly and retain it for your reference. • Because the following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in this manual. Important safety symbols WARNING Indicates that a danger of death or serious injury exists. -
Page 4: General
Safety information General Failure to meet these requirements could cause damage to the internal parts of the vacuum and void your warranty. • Read all instructions carefully. Before switching the vacuum on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate at the rear of the handy vacuum cleaner (battery contact side). - Page 5 – An explosion or fire may occur. • If the product makes a strange sound or emits a smell or smoke, turn off the product immediately, and then contact a Samsung service center. – Electric shock or fire may occur.
- Page 6 – If there is foreign matter on the wheel of the brush which cannot be removed easily, contact a Samsung service center. • When the spin brush inside a brush is working, do not touch the brush.
-
Page 7: Maintenance
– If water gets into the product and an error occurs, turn off the product and contact a Samsung service center. • When cleaning the washable parts, do not use alkaline detergent, acid, industrial detergent, air freshener, acetic acid, etc. -
Page 8: Clean Station
Safety information Dustbin, Washable Micro Filter, Fine Dust Filter, Metal Mesh Washable Parts Grille Filter, dry cloth Acceptable Neutral Dish washing detergent detergent Alkaline Lox, mold cleaner, etc. Acid Paraffin oil, an emulsifier, etc. Industrial NV-I, PB-I, Opti, alcohol, acetone, benzene, thinner, etc. Prohibited cleaners detergent... - Page 9 – Product malfunction or electric shock may occur. • As the Clean Station is designed for the use of Samsung Jet cordless vacuum cleaner only, do not use the Clean Station for other electronic appliances and other purposes.
-
Page 10: Battery
• When you purchase a new battery, make sure to check the model name (VCA-SBTA95) and the genuine logo. – Contact your nearest Samsung Electronics retailer or Samsung service center to purchase any consumable accessories. English... - Page 11 • Leaks from battery cells can occur under extreme usage or temperature conditions. If the liquid gets on your skin, wash the affected area quickly with water. If the liquid gets into your eyes, flush them immediately with clean water for a minimum of 10 minutes. Seek medical attention.
-
Page 12: Preparation
Preparation Accessories The accessories with the ' * ' mark may differ depending on the models. Telescopic pipe Pet Tool Combination Tool Extension Crevice Tool Flexible Tool Dust bags (1 installed, 2 extra) User manual * Charger Accessory Cradle Clean Station * Jet Dual Brush * Slim Action Brush * Accessory Cradle Holder... -
Page 13: Parts Overview
Parts overview 12 Battery release button 01 Power ( ) button 02 Suction power control buttons 13 Pipe release button 14 Pipe length adjustment button 03 Washable Micro Filter 04 Metal Mesh Grille Filter 15 Brush release button 05 Display 16 Dustbin joint 06 Dustbin release button 17 Clean Station START/STOP button... -
Page 14: Operation
Operation For detailed information, please refer to the QR code. Installing the Clean Station 1. Run the power cord of the Clean Station along the round groove at the bottom. Make sure the power cord is correctly placed so that the Clean Station stands without tilting. 2. -
Page 15: Charging The Battery
Charging the battery • When the battery level indicator turns red or the ‘Low battery’ message appears on the display, charge the battery. • You cannot use the vacuum cleaner while charging. • Make sure the back of the battery is correctly placed onto the vacuum charging part. •... -
Page 16: Using The Buttons And Display
Operation Using the buttons and display 01 Display Displays the current mode (‘MIN, MID, MAX, JET, or WET’) or the alert message. 02 Power ( Press this button to turn on or off the vacuum cleaner. When you turn on the power, the vacuum cleaner starts in the ‘MID’ mode. -
Page 17: Using The Accessory Cradle
Using the Accessory Cradle [Accessory Cradle] [Accessory Cradle + Accessory Cradle Holder] • Before charging the additional battery, plug in the charger. • Dust that remains in the accessory may fall when you detach it from the vacuum cleaner. When you finish using the vacuum cleaner, shorten the Telescopic Pipe and operate the vacuum cleaner in the 'MAX' mode for more than 10 seconds. -
Page 18: Using The Accessories
Operation Using the accessories Detaching the accessories • To detach the accessories, press the release button on the back of each accessory. • Before detaching the accessories, operate the vacuum cleaner in the 'MAX' mode for 10 seconds to prevent any foreign matter remains inside the accessory. - Page 19 Spray Spinning Sweeper Use to clean a wood and linoleum floor with a wet Reusable wet pad pad. • The Spray Spinning Sweeper does not have a Spin disk dust suction function. Using the reusable wet pad • When attaching the wet pad, make sure the pad is in the center of the spin disk.
-
Page 20: Maintenance
Maintenance Cleaning the Clean Station Replacing the dust bag When the START/STOP button turns red, you should replace the dust bag. Cleaning the Premotor Filter Use the handle to lift the filter off and shake over a bin to remove dust. Cleaning the Fine Dust Filter Shake the Fine Dust Filter over a bin to remove dust. -
Page 21: Cleaning The Vacuum Cleaner
Cleaning the vacuum cleaner For detailed information, please refer to the QR code. Dustbin/Washable Micro Filter CAUTION • After cleaning the dustbin and Washable Micro Filter with water, you should dry them completely in the shade for more than 24 hours before use. When heat is applied, part deformation may occur. - Page 22 Maintenance Fine Dust Filter Make sure to turn off the product before cleaning the filter. • Twist and pull off the Fine Dust Filter, and tap it gently to remove the dust. • Wash the filter with running water once a month to maintain the best performance of the filter. •...
- Page 23 Slim Action Brush CAUTION • Do not clean the brush with water. • When foreign matter remains on the brush, remove it with a wet tissue or a dry cloth. NOTE If the spin brush does not work after cleaning the Slim Action Brush, the overheating prevention device of the motor may have been enabled.
-
Page 24: Appendix
• Install the Clean Station in a place where there are no objects that could break and cause damage. • If you have a problem with installing the Clean Station, contact a Samsung service center. English... - Page 25 • If the product does not work after you charge the battery, replace the battery. If it still does not work with the new battery, contact a Samsung service center. • Spare batteries and the Accessory Cradle chargers need to be purchased separately.
- Page 26 Do not boil the wet pad. • Use a genuine wet pad of Samsung Electronics for the Spray Spinning Sweeper. • If the Spray Spinning Sweeper is used without a wet pad, any product malfunction will not be covered by warranty and a service fee will be charged.
- Page 27 • When the dust bag in the Clean Station is filled with dust, the Clean Station may stop due to the overheating prevention device of the motor. Replace the dust bag and then use the Clean Station. • If there is a larva in the suctioned dust, it can multiply in the dust bag. Clean the Clean Station with a wet tissue and replace the dust bag.
- Page 28 Appendix • When cleaning, be careful that the side of the brush does not bump into a molding part, a wall, furniture, etc. and cause staining. – For a slight stain, remove it with a wet tissue or a cleaner. •...
- Page 29 Maintenance NOTE • If the inner part of the Spray Spinning Sweeper is clogged with large foreign matter, spinning speed decreases or the spin disk stops. CAUTION • Do not push the vacuum cleaner while it is stored in the Clean Station. –...
-
Page 30: Troubleshooting
• Replacement filters are available at your local Samsung service agent. • Materials of a mat (childcare center mat, noise prevention mat for Static electricity occurs between floors, etc.) may cause the static electricity. - Page 31 Problem Solutions • As this product has the overheating prevention device of the motor, product will stop operation temporarily for the following conditions. After correcting the cause of the problem, turn the product on again. (This case Vacuum cleaner stops may differ depending on the ambient temperature.) operation during cleaning.
-
Page 32: Product Specification
Appendix Product specification Charging and cleaning time may differ depending on the brushes and the conditions of use. Model VS20A95**** Series Power consumption (Vacuum cleaner) Based on a handy vacuum cleaner: 580 W Battery specification Li-ion 25.2 V, 2200 mAh, 7 cell Weight (Vacuum cleaner) 2.7 kg (Jet Dual Brush) Vacuum cleaner... - Page 33 Memo...
