4.5M Effective Width
To calibrate the Multiboom, the outer nozzles must be adjusted so that their effective
spray width is 1.5M each. This makes the effective width of the boom 4.5M.
Because the outer nozzles are covering an area three times as wide as each nozzle in the
center section, they must be selected to produce three times the flow of each center
nozzle at the same pressure.
Centre Tips (3 required)
Yellow 02 (Pt No. 5300-9800)
Operating Shut-off Valves
Locate the red shut-off knob on the side of each nozzle body. Rotate the knob clockwise
to shut the flow off to the tip, anti-clockwise to allow fluid through the tip. The knob may
need to be pushed in towards the nozzle body in order to relocate on the thread.
Once the tip size and effective spray width have been set, measure the flow from the tips
using a measuring jug. Calculate the boom flow rate as follows; (all flows in Litres/Minute)
Boom Flow= (Centre tip flow x 3) + (Outer tip flow x 2)
Calculate the application rate as follows;
L/Ha=
Part Number
1600-6000
3400-5400
4100-0010
5300-1900
5300-1600
5300-2600
5300-3700
5300-9800
CALIBRATION
Outer Tips (2 required)
OC06 (Pt No. 5300-3700)
DETERMINING APPLICATION RATE
Boom Flow(L/Min) x 600
Effective Spray Width (Metres) x Speed (KPH)
SPARE PARTS
Description
Nozzle Cap
Nozzle Filter
8.5mm Delivery Hose
Nozzle Body Inner
Nozzle Body Outer
Swivel Body Outer
OC-06 Brass Nozzle Tips
110WR02 Nozzle Tips
Quantity Required
5
5
By the metre as needed
3
2
2
2
3
5
Boom Flow @ 2bar
L/Min
5.83
