Summary of Contents for AEE MACH6
- Page 1 Product name: MACH6 AEE UNMANNED AIRCRAFT SYSTEM Professional Leading Model Name: Y12 USER'S MANUAL V1.0 Pictures only for reference. Before flying this aircraft, please read this manually carefully and completely. Keep it safe for later reference.
- Page 2 Welcome message from the General Manager of AEE Technology Inc. General Manager of AEE Technology Inc.
- Page 3 Table of Contents 1. Introduction............................1 1.1 Introduction............................1 1.2 Safety Precautions........................1 1.3 UAV Preparation...........................3 1.4 Installation of remote controller antenna..................11 2. Aircraft ..............................12 2.1 Overview of aircraft ........................12 2.2 Flight mode ..........................12 2.3 Navigation and Status Lights......................12 2.4 Auto takeoff/landing ........................13 2.5 One-button route ........................13 2.6 Auto return ..........................15 2.7 Radar avoidance function ......................16...
- Page 4 5.3 Battery level of remote control ....................25 5.4 Drone operation .........................26 5.5 Flight mode switch ........................29 5.6 Illustration and function for main interface of remote control .............30 5.7 Illustration of setting interface ....................35 5.8 Illustration of Map interface ......................43 5.9 Route mission ..........................47 6.
- Page 5 1. Introduction 1.1 Introduction Thank you for purchasing the AEE Mach6 Hexcopter. This advanced UAV systems offers some key industry leading features including but not limited to : 1) Up to 50 mins flight time, 2) Up to 13 Lbs of paylaod lift, 3) Up to 3 Smart controlable Payloads attached to UAV at the same time.4) Smart...
- Page 6 ☆Ensure that the drone is the center of the circle when taking off and landing, and there are no moving people or obstacles within a radius of 30 foot. When operating this AEE unmanned aircraft system product, the drone should only be allowed to fly in a safe area away from the crowds, and it is important to pay attention to your own safety and people around you.
- Page 7 AEE Unmanned Aircraft System Profes i na Leading 1.3 UAV Preparation 1.3.1 Unfolding, locking and folding of drone arm as shown below: Unfold Hold Complete - 3 -...
- Page 8 AEE Unmanned Aircraft System Profes i na Leading 1.3.2 landing gear quick assembly & disassembly Assembly & disassembly of long tripod as shown below: Please note there are two leg sizes depending on the type of terrain you are launching in.
- Page 9 AEE Unmanned Aircraft System Profes i na Leading Assembly & disassembly of short tripod as shown below: - 5 -...
- Page 10 AEE Unmanned Aircraft System Profes i na Leading 1.3.3 Propeller Installation The positive propeller and counter propeller are marked with “CW” and “CCW” respectively. The propellers are installed at the consequence of positive – counter – positive – counter – positive –...
