ECFM 17 / ECFM 20
PARTS LIST
Euroclean MODELS 56649017, 56649018
6/02 revised 7/02 FORM NO. 56042428

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECFM 17 and is the answer not in the manual?

Questions and answers

Summary of Contents for Euroclean ECFM 17

  • Page 1 ECFM 17 / ECFM 20 PARTS LIST Euroclean MODELS 56649017, 56649018 6/02 revised 7/02 FORM NO. 56042428...
  • Page 2 02-6 TABLE OF CONTENTS 02-7 ECFM 17/20 DESCRIPTION Handle Assembly ... 2-3 Apron and Carriage Assembly ... 4-5 Gear Head Unit ... 6-7 Use the numbers from the “Ref. No.” columns in this parts list. Specify the model number, serial number and type number of the machine.
  • Page 3: Handle Assembly

    HANDLE ASSEMBLY ECFM 17/20 FORM NO. 56042428 02-6 02-7...
  • Page 4: Handle Assembly

    Ref. No. Description 56649485 Handle Assembly with cable, 50’, 14 x 3 56649484 Handle Assembly without cable 56649486 Switchbox Assembly NOTE 56649747 Decal, ECFM 17 56649748 Decal, ECFM 20 56649000 Switchbox Screw 56649489 Handle Bar 56649001 Handle Bar Screw 56649497...
  • Page 5: Apron And Carriage Assembly

    APRON AND CARRIAGE ASSEMBLY 02-6 ECFM 17/20 ECFM 17 ECFM 20 FORM NO. 56042428...
  • Page 6: Apron And Carriage Assembly

    02-6 APRON AND CARRIAGE ASSEMBLY ECFM 17/20 Item Ref. No. Description 56649362 Apron-Carriage Assy (as shown) (ECFM 17) 56649366 Complete Carriage Assy (as shown) (ECFM 20) 56649277 Handle Set Screw 56649346 Handle Adaptor 56649348 Lock Link Screw 56649347 Handle Adaptor Link...
  • Page 7: Gear Head Unit

    GEAR HEAD UNIT ECFM 17/20 FORM NO. 56042428 02-6 02-7...
  • Page 8: Form No.

    02-6 GEAR HEAD UNIT 02-7 ECFM 17/20 Item Ref. No. Description 56649667 Gear Head Unit (1 H.P.) (ECFM 17) 56649680 Motor (1 H.P.) (ECFM 17) 56649659 Transmission (ECFM 17) 56649681 Motor (1-1/2 H.P.) (ECFM 20) 56649659 Transmission (ECFM 20) 56649320...
