Page 1: Parts List
Xtrac PARTS LIST Euroclean MODEL 56265301 6/05 revised 2/06 FORM NO. 56042466... - Page 2 ACCESSORIES AVAILABLE BRUSH 56265340 Brush Assembly 12” ACCESSORY TOOLS 56314402 Wand Assembly w/Soft and Hard Floor Tools 56265173 Wand Assembly w/Soft Floor Tool 56262209 Stand Up Wand 56220109 Hand Tool 56220070 Upholstery Hand Tool 56265368 8’ Hose w/Waterline 56265174 15’ Hose w/Waterline...
-
Page 3: Table Of Contents
05-6 TABLE OF CONTENTS Xtrac 06-2 DESCRIPTION Back Panel Assembly ... 2-3 Base System ... 4-5 Brush System ... 6-7 Decal System ... 8-9 Handle System 12 ... 10-11 Recovery System ... 12-13 Solution System ... 14-15 Wiring Diagram ... 16-17 Use the 8 digit numbers from the “Ref. -
Page 4: Back Panel Assembly
05-6 BACK PANEL ASSEMBLY Xtrac FORM NO. 56042466... - Page 5 05-6 BACK PANEL ASSEMBLY Xtrac Item Ref. No. Qty Description 56265107 Switch, Rocker 56265356 Cord, Power 16/3, SJT 56755726 Barb, Hose Male 56009205 Wsh, Flt SS .219 x .500 x .047/.062 56002896 Scr, Pan Phil SS 10-24 x .62 56009078...
-
Page 6: Base System
05-6 BASE SYSTEM Xtrac 05-8 FORM NO. 56042466... - Page 7 05-6 BASE SYSTEM 05-8 Xtrac Item Ref. No. Qty Description 56265393 Bushing .31 x .50 x 1.18 56264382 Adaptor, Barbed 56002082 Pin, Spr .19 x 1.00 56002836 Nut, Hex Nyl Loc SS 10-24 56002938 Wsh, Flt SAE SS 5/16 56003272...
-
Page 8: Brush System
DECAL SYSTEM BRUSH SYSTEM 05-6 Xtrac FORM NO. 56042466... - Page 9 05-6 BRUSH SYSTEM DECAL SYSTEM Xtrac Item Ref. No. Qty Description 56265204 Bearing/Spindle Kit Spindle, Drive Washer, Bearing Bearing, Block Sheave Poly-V 6J17 Bearing, Ball Bearing, Ball 56265344 Bracket, Motor Tension 56265340 Brush Assembly 12 56265077 Motor, 115V, 1/4 HP...
-
Page 10: Decal System
05-6 DECAL SYSTEM Xtrac FORM NO. 56042466... - Page 11 05-6 DECAL SYSTEM Xtrac Item Ref. No. Qty Description 56016770 Decal, Xtrac 56016771 Decal, Switch / Breaker 56016772 Decal, Operation Instructions FORM NO. 56042466...
-
Page 12: Handle System 12
HANDLE SYSTEM 18 HANDLE SYSTEM 12 05-6 Xtrac FORM NO. 56042466... - Page 13 05-6 HANDLE SYSTEM 18 HANDLE SYSTEM 12 Xtrac Item Ref. No. Qty Description 56002192 Scr, Pan Phil 10-24 x .75 56003092 Scr, Pan Phil Plastite 4-20 x .62 56264123 Ratchet 56265053 Button, Spray 56265098 Switch, SPDT Snapaction 56265357 Rod, Handle...
-
Page 14: Recovery System
RECOVERY SYSTEM RECOVERY SYSTEM 05-6 Xtrac FORM NO. 56042466... - Page 15 05-6 RECOVERY SYSTEM RECOVERY SYSTEM Xtrac Item Ref. No. Qty Description 56001972 Scr, Flt Phil 1/4-20 x 1.50 56265397 Tank, Recovery 12 56265346 Handle, Lid 56265398 Lid Assembly (includes item 5) 56265351 Gasket, Lid FORM NO. 56042466...
-
Page 16: Solution System
SOLUTION SYSTEM 05-6 Xtrac FORM NO. 56042466... - Page 17 05-6 SOLUTION SYSTEM Xtrac 06-2 Item Ref. No. Qty Description 56002859 Wsh, Flt SAE SS 1/4 56002507 Scr, Pan Phil 1/4-20 x .75 56002896 Scr, Pan Phil SS 10-24 x .62 56002905 Scr, Pan Phil SS 1/4-20 x 1.50 56003067 Scr, Pan Phil SS 1/4-20 x 1.00...
- Page 18 WIRING DIAGRAM SOLUTION SYSTEM Xtrac ROCKER SWITCH BLK #2 (2 Cond Cable) CIRCUIT BREAKER, 3 A. HANDLE SWITCH FORM NO. 56042466 #10 RING TERMINAL (FASTEN TO CONROL PANEL) GRN/YEL (4 Cond Cable) MOTOR, VACUUM AMP = 7.7 BLK #3 (4 Cond Cable) MOTOR, PUMP AMP = 0.6...
-
Page 19: Wiring Diagram
05-6 SOLUTION SYSTEM WIRING DIAGRAM Xtrac Item Ref. No. Qty Description 56265103 Rectifi er, 35 Amp 56265379 Circuit Breaker, W/Boot (3 Amp) 56265037 Valve, Solenoid 115V 56265380 Motor Vacuum, 115V 56203518 Carbon Brushes (set of 2) for use on 56265380...
