PAIRGAIN TECHNOLOGIES Section 363-742-102 Technical Practice Revision 01 Engineering - PLANT Series December 18, 1996 ™ PG-F 24 C RT L HANNEL MODEL FRL-742 List # PairGain # CLEI Code 150–1342-01 VARHDF0CAA 150-1342-02 VARHDFFCAA CONTENTS PAGE PRODUCT OVERVIEW 1. DESCRIPTION AND FEATURES 2.
Section 363-742-102 Revision 01 A. PRODUCT OVERVIEW four complete systems may be installed in a 23-inch COT Shelf. Each system requires one COT Line Unit 1. DESCRIPTION AND FEATURES and up to three (23-inch shelf) or six (19-inch shelf) 1.01 Channel Units.
Section 363-742-102 Revision 01 4. CERTIFICATION 5.04 PairGain will continue to repair faulty modules beyond the warranty program at a nominal charge. Contact 4.01 FCC Compliance. The FRL-742 RT Line Unit your PairGain sales representative for details and pricing. complies with the limits for Class A digital devices pursuant to Part 15 of the FCC rules.
Section 363-742-102 Revision 01 • LOOP 2 MARGIN LED Indicator 7. FRONT PANEL Yellow—HDSL line 2 margin is below a preset level. 7.01 The front panel of the FRL-742 contains the following switch, indicators, connector Off—HDSL line 2 margin is above the preset level. (see Figure 1): •...
Section 363-742-102 Revision 01 8. TERMINAL MANAGEMENT – Display Channel Status to show the current status of all channels in the system. Each 8.01 The terminal management function at the remote channel has one of the following status terminal enables a technician to monitor the entire PG-Flex conditions: system through an ASCII terminal (or equivalent) connected IDLE: The channel is not off-hook or...
Page 8
Section 363-742-102 Revision 01 Figure 4. FRL-742 DB-9 Pin Outs. A standard RS-232 (DB-9) connector on the front panel provides access to the menu interface feature via an ASCII terminal. Page 8...
Page 9
Section 363-742-102 Revision 01 Figure 5. Terminal Menu and Display Structure. Page 9...
Section 363-742-102 Revision 01 C. INSTALLATION AND TEST 10. TURN-UP AND TESTING 10.01 Table 2 provides step-by-step turn-up and test 9. UNPACKING procedures for the FRL-742 RT Line Unit. 9.01 Upon receipt of the equipment, proceed as follows: 11. TROUBLESHOOTING 1.
Page 11
Section 363-742-102 Revision 01 TABLE 3. FRL-742 RT LINE UNIT TROUBLESHOOTING Indication Problem Action POWER LED 1. One or both HDSL lines a. Make the following measurement on the RT Enclosure backplane: are no longer connected • 130 Vdc to 250 Vdc between HDSL_T and HDSL_T between the COT and RT.
