Summary of Contents for CUAV C-RTK 9P

  • Page 1 产品说明书 User manual...
  • Page 2 接口定义 Interface definition GPS状态灯 GPS Status light RTK状态灯 电源状态灯 RTK Status Power Status light light Type-C接口 Type-C interface...
  • Page 3 UART1接口定义 UART1 interface definition UART1接口 UART1 interface 天线接口 Antana interface...
  • Page 4 规格参数 184通道 卫星接收 GPS L1C/A L2C, GLONASS L1OF L2OF, GALILEO E1B/C E5b, BDS B1I B2I, QZSS L1C/A L2C 导航刷新率 RTK up to 20Hz 定位精度 RTK 0.01m + 1ppm CEP 收敛时间 RTK <10s 收集时间 冷启动 辅助启动 重新捕获 灵敏度 追踪 & 导航 -167dBm 冷启动...
  • Page 5 Specification Parameter Receiver type 184 Channels GPS L1C/A L2C, GLONASS L1OF L2OF, GALILEO E1B/C E5b, BDS B1I B2I, QZSS L1C/A L2C RTK up to 20Hz Nav.update rate Position accuracy RTK 0.01m + 1ppm CEP Convergence time RTK <10s Cold starts Acquisition Aided starts Reacquisition...
  • Page 6 配件清单 Packing list 地面端 C-RTK 9P硬件 多星多频蘑菇头天线 MMCX-SMA天线延长线 TYPE-C USB地面端数据线 移动端 C-RTK 9P硬件 多星多频螺旋天线 MMCX-SMA天线延长线与支架-30cm GH1.25 6P数据线 TYPE-C V5+/V5 nano飞控数据线 TYPE-C Pixhack系列飞控数据线 *配件清单以销售页面为准。 Ground Modular C-RTK 9P Multi satellite and frequency mushroom antenna MMCX-SMA antenna extension line TYPE-C USB ground data line...

  • Page 7: Relevant Information

    Please read the instructions carefully. Please note that satellite positioning is affected by environ mental conditions. Please do not damage the product by violence. 相关资料 产品使用教程， 请访问CUAV官方文档中心： http://doc.cuav.net Relevant Information Product use tutorial. Please visit CUAV official document center: http://doc.cuav.net...
