SAMBA 55/56
Operating voltage
S/N ratio
Directivity
Max. input sound pressure level 100 dB SPL (1 kHz) Maximum distortion 1 %
Radio frequency protection

7.2 Making a dial-up networking

The following description is focussed on the SAMBA phone using the
Microsoft Windows® tools such as Dial-up Networking. It is assumed that
the delivered USB driver has already been installed. During the network
installation, please follow the on-screen instructions, too.
Click Start button, point to Program, go to Accessories,
Communication then click Dial-up Networking.
Double click to the Make New Connection icon.
Figure 29: Make new connection.
The next dialog box click the Next button.
Figure 30: Continue the new connection.
Activate the Dial-up to private network radio button, then click
Next.
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
DC 1 to 3 V (min.)
55 dB minimum (A-Curve at 1 kHz, 1 Pa)
Omni-directional
Over 800-1200 MHz and 1700-2000MHz, S/N ratio
500 dB minimum (signal 1 kHz, 1 Pa)
VERSION 1.03
