SAMBA 55/56

7 Appendix

7.1 Accessory headset for SAMBA

A different microphone inputs and a different speaker outputs are supported
by the SAMBA modem. The retractable Headset included in the package
(see also figure below) fully compatible with SAMBA phone which
supports a 2.5mm headset jack connector is designed to do two things at
once, if those two things are driving and talking on the cell phone. The
retractable Headset is lightweight, super-easy to use, comfortable, and has
great incoming and outgoing sound quality. Retractable quality earpiece and
microphone pulling out to desired length independently. The retractable
cord length is 78 mm. The headset length is 1 m. You have just to connect it
to the corresponded connector of SAMBA. To wear the earpiece, simply
pull it out of its casing slowly until you reach the sufficient length and sit it
inside the ear. Should the length of the cable too long/short, pull the cable
slowly out or retract while holding the both sides onto the cable until the
length is suitable.
If the user is using other external headset please follow the characteristics
for different microphone inputs and different speaker outputs:
Items to be inspected
Sensitivity
Frequency response
Current consumption
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
Acceptance criterion
-41 ±3dB (0dB=1 V/Pa @ 1kHz)
Limits
Freq. (Hz)
100
200
300
1000
2000
3000
3400
4000
1 mA (max.)
VERSION 1.03
Lower limit Upper limit
-38
-38
-50 -38
-44 -38
-44 -34
-44 -34
-44 -34
-47 -34
