Your generator has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
DANGER:
You WILL be KILLED or SERIOUSLY HURT if you do not follow the instructions in this operator's
manual.
Thank you for your purchase.
SAVE THiS MANUAL FOR FUTURE REFERENCE
Su nuevo generador ha sido diseñado y fabricado de conformidad con estrictas normas para brindar fiabilidad, facilidad de
uso y seguridad para el operador. Con el debido cuidado, le brindará muchos años de sólido y eficiente funcionamiento.
PELiGRO:
El incumplimiento de las instrucciones en este manual del operador puede CAUSARLE LA MUERTE
O LESIONARLE GRAVEMENTE.
Le agradecemos su compra.
GUARDE ESTE MANUAL PARA FUTURAS CONSULTAS
OPERATOR'S MANUAL
MANUAL DEL OPERADOR
PORTABLE GENERATOR
GENERADOR PORTáTiL
NEUTRAL FLOATiNG
PUNTO NEUTRO FLOTANTE
HU2250
Advertisement
Table of Contents
Related Manuals for Husky HU2250
Summary of Contents for Husky HU2250
- Page 1 OPERATOR’S MANUAL MANUAL DEL OPERADOR PORTABLE GENERATOR GENERADOR PORTáTiL HU2250 NEUTRAL FLOATiNG PUNTO NEUTRO FLOTANTE Your generator has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
- Page 2 See this fold-out section for all of the figures referenced in the operator’s manual. Consulte esta sección desplegable para ver todas las figuras a las que se hace referencia en el manual del operador.
- Page 3 Fig. 1 A - Recoil starter grip (mango del arrancador retráctil) I - AC circuit breaker (disyuntor de circuito de CA) B - Air filter (filtro de aire) J - Engine switch (interruptor del motor) C - Choke lever (palanca del anegador) K - Oil drainage bolt (perno de drenaje de aceite) D - Oil cap/dipstick (tapa de relleno de aceite/varilla medidora de aceite) L - Handle (mango)
- Page 4 Fig. 7 Fig. 5 Fig. 3 A - Handle (mango) A - Fuel cap (tapa del tanque de combustible) B - Lanyard with pin (correa con pasador) B - Fuel tank (tanque de combustible) A - Wheels (ruedas) B - Axle (eje) Fig.
- Page 5 Fig. 9 Fig. 11 Fig. 13 A - Move choke lever left to run (desplace izquierda la palanca del anegador para poner en marcha) B - Move choke lever right to start (desplace derecha de la palanca del anegador para arrancar) Fig.
-
Page 6: Table Of Contents
TABLE OF CONTENTS Introduction ..................................2 Important Safety Instructions ............................3-4 Specific Safety Rules ............................... 4 Symbols ..................................5-7 Electrical ..................................8-9 Features ..................................10 Assembly ..................................11 Operation ..................................12-13 Maintenance ................................14-16 Troubleshooting................................17 ... -
Page 7: Important Safety Instructions
iMPORTANT SAFETy iNSTRUCTiONS Keep all bystanders, children, and pets at least 10 feet away. DANGER: Wear sturdy and dry shoes or boots. Do not operate while Carbon Monoxide. Using a generator indoors WILL KILL barefoot. YOU IN MINUTES. ... -
Page 8: Specific Safety Rules
iMPORTANT SAFETy iNSTRUCTiONS Maintain the unit per maintenance instructions in this Inspect the unit before each use for loose fasteners, fuel Operator’s Manual. leaks, etc. Replace damaged parts. SPECiFiC SAFETy RULES This generator has a neutral floating condition. This means the neutral conductor is not electrically connected to the WARNiNG: frame of the machine. -
Page 9: Symbols
SyMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SyMBOL SiGNAL MEANiNG Indicates an imminently hazardous situation, which, if not avoided, will result DANGER: in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could result WARNiNG: in death or serious injury. - Page 10 SyMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SyMBOL NAME DESiGNATiON/EXPLANATiON Safety Alert Indicates a potential personal injury hazard. Wet Conditions Alert Do not expose to rain or use in damp locations.
- Page 11 SyMBOLS SAFETy LABELS DANGER Using a generator indoors WILL KILL YOU IN MINUTES. The information below can be found on the generator. For your safety, please study and Generator exhaust contains carbon monoxide. This is a poison you cannot see or smell. understand all of the labels before starting the generator.
-
Page 12: Electrical
ELECTRiCAL EXTENSiON CORD CABLE SizE Refer to the table below to ensure the cable size of the extension cords you use are capable of carrying the required load. Inadequate size cables can cause a voltage drop, which can damage the appliance and overheat the cord. Load in Watts Maximum Allowable Cord Length Current in... - Page 13 ELECTRiCAL GENERATOR CAPACiTy CAUTiON: Make sure the generator can supply enough continuous (run- Do not overload the generator’s capacity. Exceeding the ning) and surge (starting) watts for the items you will power generator’s wattage/amperage capacity can damage the at the same time. Follow these simple steps. generator and/or electrical devices connected to it.
-
Page 14: Features
FEATURES PRODUCT SPECiFiCATiONS GENERATOR ENGiNE Rated Voltage ..............120V Engine Type ..........169cc Subaru Rated Amps ............18.75 A Cooling System ..........Forced Air Rated Output ............2,250 W Starting System ............Recoil Maximum Output ........... 2,800 W Ignition System ............T.C.I. Rated Frequency ............60 Hz Spark Plug .......... -
Page 15: Assembly
ASSEMBLy WARNiNG: WARNiNG: If any parts are damaged or missing do not operate Do not attempt to operate the generator until assembly this product until the parts are replaced. Failure to heed is complete. Failure to comply could result in possible this warning could result in serious personal injury. -
Page 16: Operation
OPERATiON BEFORE OPERATiNG THE UNiT DANGER: Only use OUTSIDE and far away from windows, doors, and vents. Carbon Monoxide. Using a generator indoors WILL KILL YOU IN MINUTES. NEVER use inside a home or garage, EVEN IF doors and windows are open. - Page 17 OPERATiON USiNG FUEL STABiLizER CAUTiON: Fuel gets old, oxidizes, and breaks down over time. Adding On a level surface with the engine off, check the lubricant a fuel stabilizer (not included) extends the usable life of fuel level before each use of the generator. and helps prevent deposits from forming that can clog the fuel system.
-
Page 18: Maintenance
CHANGiNG ENGiNE LUBRiCANT WARNiNG: See Figure 12. When servicing, use only identical Husky replacement Remove the oil cap/dipstick. parts. Use of any other parts may create a hazard or Place a container underneath the oil drainage bolt to col- cause product damage. - Page 19 MAiNTENANCE CLEANiNG THE EXHAUST PORT AND EMPTyiNG FUEL TANK/CARBURETOR MUFFLER To help prevent gum deposits in the fuel system, drain the fuel from the tank and carburetor before storing. Depending on the type of fuel used, the type and amount of lubricant used, and/or your operating conditions, the exhaust ...
- Page 20 MAiNTENANCE STORAGE When preparing the generator for storage, allow the unit to cool completely then follow the guidelines below. STORAGE TiME PRiOR TO STORiNG Less than 2 months Run the generator until the fuel tank is empty. 2 months to 1 year ...
