VERSION # 19-12-24
1 / 11
MODEL #
YNJ-1967C25-CK
Questions?
GIVE US A CALL: 1-888-980-5122
MON－FRI 8:30AM－5:30PM (PST)
TOOLS REQUIRED
Allen Wrench
(Included)
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America YNJ-1967C25-CK
Summary of Contents for Furniture of America YNJ-1967C25-CK
- Page 1 MODEL # YNJ-1967C25-CK Questions? GIVE US A CALL: 1-888-980-5122 MON－FRI 8:30AM－5:30PM (PST) TOOLS REQUIRED Allen Wrench (Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 2 / 11...
- Page 3 3 / 11...
-
Page 4: Care Advice
ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so. - Page 5 KING SIZE BED YNJ-1967C25-CK PARTS 2PCS 2PCS 2PCS 2PCS 3PCS HARDWARE 4PCS 8PCS 7PCS 8PCS 4PCS 8PCS 2.05" 1.18" 0.47" 0.79" 4PCS 5 / 11...
-
Page 6: Get Ready
GET READY Please group boards as below. 2PCS 2PCS 2PCS 2PCS 3PCS Body 6 / 11... - Page 7 Part x1PC Part x1PC Hardware x4PCS Front Attach floor protectors (#M) to the legs of the headboard and footboard. 7 / 11...
- Page 8 Part x2PCS Part x2PCS Part x2PCS Hardware x8PCS Hardware x4PCS Hardware x4PCS Hardware x8PCS Hardware x1PC Hardware x1PC Hardware x1PC 2) Align side rails to the headboard (#1) and footboard (#2), then secure by using bolts (#A) with hex nuts (#F). 1) Secure side rails (#3,4) together by aligning support legs (#5) to side rails (#3,4) and securing with bolts (#E) with...
- Page 9 Part x2PCS Part x1PC Hardware x4PCS Hardware x4PCS Hardware x4PCS Hardware x1PC Hardware x1PC Front Align slats (#8) to the side rails, then secure by using bolts (#H). Align slats (#6) to the side rails, then secure by using bolts (#B) with hex nuts (#C).
- Page 10 Part x3PCS Hardware x3PCS Hardware x1PC Front Align support legs (#7) to the slats (#6,8), then secure by using bolts (#B). 10 / 11...
- Page 11 ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the produst wobbles or feels loose,double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference.
