- Page 1 TOOLS REQUIRED Phillips Screwdriver (Not Included) Hammer (Not Included) 2 - Persons Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. 1 / 15...
- Page 2 2 / 15...
- Page 3 3 / 15...
-
Page 4: Care Advice
ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so. - Page 5 5 / 15...
- Page 6 TV STAND PARTS 2PCS 2PCS 2PCS 2PCS 2PCS 2PCS HARDWARE ACCESSORIES 20PCS 20PCS 12PCS 18PCS 5PCS 14PCS 1.97" 8PCS 4PCS 4PCS 0.75" 6 / 15...
-
Page 7: Get Ready
GET READY Please group boards as below. 2PCS 2PCS 2PCS 2PCS Body 2PCS 2PCS Doors /Shelf 7 / 15... - Page 8 Hardware x12PCS Hardware x2PCS OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 8 / 15...
- Page 9 Hardware x8PCS Hardware x10PCS Finished Side OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 9 / 15...
- Page 10 Part x1PC Part x1PC Finished Side Part x1PC Hardware x4PCS Accessory x1PC Front Part x2PCS Front Part x2PCS Part x2PCS Hardware x4PCS Please refer to page 5 for detailed instructions on how to fasten cam locks (#2) to cam bolts (#1). 10 / 15...
- Page 11 Part x2PCS Hardware x4PCS Front Part x1PC Hardware x4PCS Front 11 / 15...
- Page 12 Front Part x1PC Hardware x6PCS Accessory x1PC Accessory x6PCS Use the provided stickers (#A3) to cover exposed locks. 180° Flip Part x1PC Part x1PC Finished Side Hardware x8PCS Accessory x5PCS Accessory x1PC Front Align floor protectors (#A1) to the bottom of the feet, then secure by using a hammer.
- Page 13 Part x1PC Front Part x1PC Hardware x8PCS Accessory x8PCS Use the provided stickers (#A3) to cover exposed locks. Part x2PCS Front Hardware x8PCS Insert shelf pins (#5) to the holes of the desired shelf height. 13 / 15...
- Page 14 Front Part x2PCS Insert top portion of panel (#N) first through the lined gap. Hardware x4PCS Front Hardware x4PCS Insert fixative plates (#6) through the thin lined gaps between back and side panels, then secure by using screws (#7). [ No pre-drilled holes ] 14 / 15...
- Page 15 ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the produst wobbles or feels loose,double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference.
