Challenger
Flue Sensor Replacement
Kit Part Number
CCRKIT36
Each Kit Includes:
• Temperature Sensor
Recommended Tools:
• Phillips Head Screwdriver
• Pliers
WARNING
!
Indicates a potentially hazardous situation which,
if ignored, can result in serious injury or substan-
tial property damage.
WARNING
!
For your safety, turn off electrical power supply
at service panel and allow unit to cool before pro-
ceeding to avoid possible electrical shock and
scald hazard. Failure to do so can cause severe
personal injury or death.
2020-35 - Challenger Flue Sensor Replacement
Revised 9/22/2022
Description
Flue Sensor Replacement
NOTICE
Indicates special instructions on installation, operation
or maintenance, which are important to equipment
but not related to personal injury hazards.
WARNING
!
Failure to follow instructions below can result in
severe personal injury or damage if ignored.
•
•
•
Model
All Models
Instructions are for a qualified installer/ ser-
vice technician only.
Read all instructions before proceeding.
Follow instructions in proper order.
