Flue Sensor Repair Kit
for Prestige Solo 175, 250 and 399
Kit Part Number: PSRKIT77

Parts List

1. Flue Sensor Mounting Plug (PSPLG06)

Recommended tools:

A. Vise grip
B. 10 mm or adjustable wrench
C. Can of WD-40
D. Clean dry cloth
E. Steel wool or fine metal sand paper
F. Fine metal file
G. Soap & water solution
W RNING
Indicates a potentially hazardous situation
which, if ignored, can result in serious
injury or substantial property damage.
W RNING
For your safety, turn off electrical power
supply at service panel and allow unit to cool
before proceeding to avoid possible electrical
shock and scald hazard. Failure to do so can
cause severe personal injury or death.
Fig. 1: Flue Sensor Mounting Plug
NOTI E
Indicates special instructions on installa-
tion, operation or maintenance, which are
important to equipment but not related to
personal injury hazards.
W RNING
Failure to follow instructions below can
result in severe personal injury or damage if
ignored.
Instructions are for a qualified installer/
service technician.
Read all instructions before proceeding.
Follow instructions in proper order.
