- Page 1 SWPSI2000/SWPSI3000 2000W/3000W Pure Sine Wave Inverter Information for use PRODUCT INFO streetwize.online/SWPSI2000 Produktinformation Information du produit Información sobre el producto...
- Page 2 2000W Pure Sine Wave Inverter 3000W Pure Sine Wave Inverter SWPSI2000 SWPSI3000 2000W Continuous Power 3000W Continuous Power 4000W Peak Output 6000W Peak Output Table 1 Safely converts your 12V DC Battery to a 230V AC power supply IMPORTANT: This inverter is only suitable for use with 12V batteries only.
- Page 3 Intention For Use Thank you for purchasing this Pure Sine Wave inverter from Streetwize. This inverter safely converts your vehicle’s 12V DC battery into a 240V AC power supply for using standard UK electrical appliances that totals up to its continuous output as stated in Table 1.
-
Page 4: Product Elements
Do not expose the inverter to temperatures over 40oC. CAUTION! Do not use the inverter with the following equipment: Class 1 appliances. See Class 1/Class 2 section. Product Elements 1. Streetwize Pure Sine Wave Inverter 2. Battery connection cables... - Page 5 Class 1 / Class 2 As mentioned in the Intention For Use section, this product is primarily designed for operating Class 2 appliances, which don’t require earthing provisions. Class 1 Class 2 Symbol Earth Wiring Present Insulation Basic Insulation Double Insulation Appliance casing Metal Plastic...
- Page 6 Operating Instruction Optimum Working Conditions For safe & optimum performance, please install the inverter in a location that is: • Dry - The inverter should not be near any liquid or moisture. • Cool - Keep it away from any high heat source. •...
-
Page 7: How To Replace The Fuses
Using The Inverter Once a safe and secure connection to the battery terminals have been made, you can proceed to use the inverter. IMPORTANT: Before powering any appliances via the inverter, make sure the inverter is switched OFF via the unit’s power switch. With the battery connection securely made. - Page 8 4. Once the screws are removed, slide off the top panel and place it on the side. You will see the inverter’s motherboard (see Figure 6). Fig 6 Fig 7 5. There are eight 30A fuses altogether. The fuses are paired together and they are located inbetween the yellow marked components as shown in Figure 7.
-
Page 9: Troubleshooting
Troubleshooting Table 3 outlines possible troubleshoots along with its suggested solutions. Troubleshoot/Problem Possible Cause Suggested Solution Turn off the inverter and dis- connect it from the battery. Then reconnect the inverter Poor battery connection to the battery and check to see if the connection is correct Turn off the inverter and disconnect it from your 12V... -
Page 10: After Use
After Use After you have finished using the inverter (or when the inverter is not in use), turn off the unit and make sure your vehicle’s fully switched off. Then disconnect the inverter from the 12V power supply. When disconnecting from the battery, disconnect the negative cable first, followed by the positive cable. -
Page 11: Technical Specifications
Technical Specifications 2000W Pure Sine Wave Inverter SWPSI2000 Supplier Code Streetwize 2000W Pure Sine Wave Inverter Product Name 2000W Continuous Output 4000W Peak Output 12V DC Input Voltage 230V AC Output Voltage UK sockets USB Output 5V DC Fuse requirements... - Page 12 Streetwize, Ashburton Road West, Trafford Park, Manchester, M17 1RY For Product Support: E: support@streetwizeaccessories.com T: +44 (0)161 447 8597 For Trade Enquiries: E: sales@streetwizeaccessories.com T: +44 (0)161 447 8580 EU Regd. Address: Ace Supply Co (Europe) Ltd. D02 A098, ROI...
