ADC H4TU-C-319 List 1 Quick Installation page 6

(a)
Message Description
A=xx The Attenuation (A) message appears followed by xx, where xx is the highest loop
attenuation of all HDSL interfaces.
ACQ1 or ACQ2 The multiplexers of the H4TU-C and H4TU-R are trying to establish synchronization over
HDSL4 Loop 1 or Loop 2.
ARM Armed to respond to Intelligent Repeater Loop (ILR) codes.
BAD RT? The H4TU-C is not receiving a response from the H4TU-R.
FERR A framing bit error occurred at H4TU-C DSX-1 input.
HxES H4TU-C Loop 1 or Loop 2 Cyclical Redundancy Check (CRC) error. (Loop 1 has display
priority over Loop 2.)
LBPV A local bipolar violation has been received at the DSX-1 input to the H4TU-C.
1=xx or The power of the received HDSL4 signal on each loop relative to noise (S/N with respect
2=xx to 21.5 dB). (xx denotes lowest margin in dB for Loop 1 and Loop 2.)
MNGD The H4TU-C is under control of the HMU-319 network management unit.
PWR FEED OFF HDSL4 span power is turned off.
PWR FEED ON HDSL4 loop is not grounded or shorted.
SIG1 or SIG2 H4TU-C and H4TU-R transceivers are trying to establish contact with each other over
HDSL4 Loop 1 or Loop 2.
(a) Normal operating messages are in bold.
Table 4. Front-Panel Configuration Options Using MODE and SEL
Display Code Description (default values in bold).
EQL Sets the DSX-1 Equalizer to: 0 (0 to 132 ft.), 133 (133 to 265 ft.), 266 (266 to 398 ft.),
399 (399 to 532 ft.), 533 (533 to 655 ft.).
RLBO Sets the H4TU-R line buildout to 0 dB, -7.5 dB, or 15 dB.
LPBK Enables (ENA) or disables (DIS) SmartJack loopback commands.
PWRF OFF = disables HDSL4 powering; AUTO = -185 Vdc or ±123 Vdc (depending on number of
downstream units detected); LOW = -185 Vdc; and HIGH = ±123 Vdc.
HBER 1E-6 or 1E-7 = alarm activates when the HDSL4 BER alarm threshold exceeds 10
NONE = prevents generation of a system alarm due to BER.
DBER Enables (ENA) or disables (DIS) fixed 24-hour DSX-1 BER alarm threshold.
LBTO Loopback timeout = NONE, 20, 60, 120 minutes, 8 hr, and 24 hr.
ALM Enables (ENA) or disables (DIS) alarm indications on pin H.
DS1 DSX-1 line code = AUTO, B8ZS, AMI.
FRMG DS1 frame formatting = AUTO (auto framing mode), SF (SuperFrame), ESF (Extended
SuperFrame), or UNFR (unframed mode).
RDA Enables (ENA) or disables (DIS) alarm indications due to remote DS1 LOS at the H4TU-R
input.
ALMP Enables system to output an alarm pattern: AIS or LOS.
BPVT Enables (ENA) or disables (DIS) Bipolar Violation Transparency.
NLBP Enables the H4TU-R to transmit either AIS or LOS towards CI for any network loopback.
TLOS Enables (ENA) or disables (DIS) a logic loopback at the H4TU-R when an LOS occurs at its
DS1 input.
RTPV Enables (ENA) or disables (DIS) remote provisioning.
PBOC Configures the power output levels of the H4TU-R customer unit toward the network.
Default (DEF) or enhanced (ENH).
PBON Configures the power output levels of the H4TU-C network unit toward the customer.
Default (DEF) or enhanced (ENH).
(a) Front-panel codes scroll in the order listed. The configured selections follow each code
(b) Default values are in bold..
Table 5. Front-Panel System Information Messages (Scroll Mode)
Code Description
VER x.xx Software version number of the
H4TU-C.
LIST xx List number of the H4TU-C-319. LATT xx
FRM xxxx Frame pattern received from the
DSX-1 (SF, ESF, UNFR).
(a) To scroll through system information messages, press the MODE pushbutton for 3 or more seconds.
Messages display in the order listed.
Copies of this publication or the user manual (LTPH-UM-1031-xx)
can be downloaded from the ADC website at www.adc.com. To
order a hard copy, contact your sales representative.
Table 3. Front-Panel Diagnostic Messages
Code Description
CODE xxxx Line code (AUTO, AMI, or B8ZS).
Default is AUTO.
Loop attenuation (0 to 50 dB).
Default is 38.
MARG xx Margin threshold (0 to 15 dB).
Default is 4.
(a)
-6 -7
or 10 .
(a)
