- Page 1 ELLWOOD ASSEMBLY GUIDE SCAN ME www.furniturebox.co.uk Scan QR code for more tips, advice and assembly video or visit furniturebox.co.uk/club/ellwood-chair...
- Page 2 Important - Please read these instructions fully before starting assembly SAFETY AND NO POWER TOOLS CARE ADVICE SAFETY AND CARE ADVICE • Check you have all the components and • Only clean using a damp tools listed. cloth and mild detergent, do no use bleach or •...
- Page 3 PLEASE CHECK CAREFULLY AND MAKE SURE YOU HAVE ALL FITTINGS AND TOOLS LISTED BELOW BEFORE YOU START. NOTE: The quantities above are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. www.furniturebox.co.uk...
- Page 4 STEP Use a clean, flat, soft surface to avoid any bumps or scratches. Attach the castor wheels [G] to each of the 5 leg spokes on base [E] - these should pop into place. Then place hydraulic lift [D] into the hollow within the legs base [C] (the thicker end of the hydraulic lift goes...
- Page 5 Your weight, when you sit on it, will ensure the seat and legs remain securely connected. STEP Attach the 2x arms [C] to the seat base [B]. Use 2x bolts [H] per arm and tighten with Allen key [K]. www.furniturebox.co.uk...
- Page 6 Attach the seat back [A] to the seat base and arms using 2x bolts [I] on either side. STEP ATTENTION: Cover all exposed bolt heads with the covers [J] - x4 on either side. Check overall stability. Your chair is now ready to use. www.furniturebox.co.uk...
- Page 7 FULL ASSEMBLY INSTRUCTIONS www.furniturebox.co.uk...
- Page 9 www.furniturebox.co.uk...
- Page 10 The cushions (foam inserts and covers) are not covered by the guarantee.
