Coopers of Stortford 8161 Instructions

2 Drawer Filing Cabinet

WARNING

• Do NOT get wet. Wipe up
spillages immediately to
avoid stains and damage
to filing cabinet.
• It is recommended that
the filing cabinet is
located on a flat level
surface.
• Do NOT locate on a
downward slope due to
risk of injury as this will
cause the drawers to fall
open unaided and will
cause the filing cabinet
itself to over balance and
tip forwards.
• Take care when moving
the filing cabinet. It is
recommended to remove
all files from the drawers
before moving.
• Distribute weight load
evenly between drawers.

CLEANING

• Wipe clean with a soft
damp cloth.
• Polish using standard
household furniture polish.

DISPOSAL

• Dispose of all paper, cartons
and plastic in accordance with
your local recycling
regulations. At the end of the
product's lifespan please
dispose of it at an authorised
household waste recycling
centre.
Please read carefully before use and retain for future reference.

Parts and assembly

A. FRONT PANELS OF DRAWERS
B. SIDE PANELS OF DRAWERS
C. BOTTOM PANELS OF DRAWERS
D. BACK PANELS OF DRAWERS
E. TOP PANEL
F. SIDE PANELS
G. KICKBOARD
H. FRONT CROSSBAR
I. BACK CROSSBAR
J. BACK PANEL
B
B
C
D
8161/8162
x2 1. SHORT SCREWS
x4 2. LONG SCREWS
x2 3. LABEL PLATE
x2 4. HANDLES
x1 5. SCREWS FOR PLATES AND HANDLES
x2 6. CAM LOCKS (1 BOLT AND 1 DRUM/SET) 18 SETS
x1 7. WOODEN PLUGS
x1 8. METAL BARS
x1
x1
1. Attach 2 side panels (B) to front panels( A) using cam
lock (6).
6
2. Slide in Bottom Panel of Drawers (C) between the assembled section,
aligning it with the grooved sections.
Fix Back Panels of Drawers (D) to assembled section using Short Screws
3.
(1) and Long Screws (2). Repeat steps 1-3 for both drawers.
2
1
Instructions
x18
x8
x2
x2
x12
x12
x4
Please turn over
