Coopers of Stortford 8267 Instructions

SHOE STORAGE SET

Parts List

Ref Part
A1,A2 Drawer front panels
B Drawer side panels
C Drawer back panels
D Drawer bottom panels
E Drawer large shelves
F Drawer small shelves
G Top
H Side panels
2-person assembly recommended
•
Assemble on a soft, flat surface to protect finished surfaces.
•
Please note, A1 is the top drawer front and A2 is the bottom drawer front. If
•
these are assembled incorrectly the top drawer will not open.

Assembly

Attach side panels (B) to the front
•
panel (A) using long screws (N).
Insert small shelves (F) into slots on
•
side panels (B) and fix using long
screws (N).
Attach the back panel (C) to the side
•
panels (B) using long screws (N).
Repeat for second drawer.
•
Continued overleaf
Instructions
Qty Ref Part
2 I Base
4 J Back panel
2 K Bolts
2 L Allen Key
4 M Dowels
4 N Long Screws
1 O Short Screws
2 P Handles & Bolts
Attach bottom panel (D)
•
to the assembled drawer
using short screws (O).
Insert large shelves (E)
•
into slots and fix using
long screws (N) and
attach handles (P) to the
drawer.
